- Chemical Metering Pump Type
- Peristaltic
- Flow Rate Output Control
- Fixed
- Max. Flow (gpd) - Pumps
- 5.00 gpd
- Voltage
- 120V
- Max. Pressure - Pumps
- 25 psi
- Voltage - Pumps
- 120V AC
- Phase - Pumps
- 1
- Max. Viscosity - Pumps
- 100 cps
- HP - Pumps
- 1/40 hp
- Reproducibility - Pumps
- +/-5.0%
- Tubing Material - Peristaltic Pumps
- Santoprene
- Suction Lift
- 25 ft
- Body Material
- Polycarbonate
- Reproducibility
- +/-5.0%
- Pump Type
- Peristaltic
- Motor RPM
- 18 RPM
- Self-Priming
- Yes
- Features
- Integral 24 Hour Clock and 24 Programmable Events.
- Number of Feeds
- 1
- Max. Flow (GPD) - Pumps
- 5.00 gpd
- Item - Chemical Metering Pumps
- Chemical Metering Pump
- Standards
- CE, cULus, NSF/ANSI 50, NSF/ANSI 372, NSF/ANSI 61
- Head and Fitting Material - Pumps
- Polycarbonate/Polypropylene/PVC
- cc/Min.
- 13.1cc/mÃn.
- Seals and O-Rings - Pumps
- Santoprene
- Max. Pressure
- 25 psi
- Includes
- 1/4 in Injector, 20 ft Roll of Suction/Discharge Tubing, Pump Tube, Weighted Suction Line Strainer, (3) 1/4 in Connecting Nuts, (3) 1/4 in Ferrules
- Hz
- 60 Hz
- Item
- Peristaltic Chemical Metering Pump
- Tubing Material
- Santoprene
- Max. Viscosity
- 100 CPS
- Min. Flow Rate
- .003 gpd
- Phase
- Single
- Motor Speed (Maximum)
- 18 RPM
- Fitting Material
- Polypropylene/PVC
- Roller Material
- Polyethylene
- Ambient Temperature (Maximum)
- 104 Degrees F
- Priming
- Self-Priming
- Motor Mounting Type
- Horizontal, Vertical
- Electrical Connection Type
- Plug-In
- Flow Rate (Maximum)
- 5 gpd
- Media Temperature (Minimum)
- 32 Degrees F
- Pressure (Maximum)
- 25 psi
- Degassing Valve Included
- No
- Control Programs
- 7 Day/24 Hour Timer
- Discharge Connection Type
- NPT
- Horsepower (Maximum)
- 1/40 hp
- Chemical Compatibility
Acetic Acid 20%,Ammonium Hydroxide,Beer Yeast,Calcium Chloride,Caustic (Sodium Hydroxide),Chromic Acid 10%,Chromic Acid 30%,Chromic Acid 5%,Chromic Acid 50%,Citric Acid 50%,Ethyl Acetate,Ethylene Glycol,Formaldehyde,Formaldehyde 40%,Glucose,Glycerin,Hydrochloric Acid 10%,Hydrochloric Acid 20%,Hydrochloric Acid 30%,Hydrochloric Acid 37%,Hydrofluoric Acid 20%,Hydrofluoric Acid 75%,Muriatic Acid,Nitric Acid 10% Solution,Nitric Acid 20% Solution,Phosphoric Acid 100%,Phosphoric Acid 40%,Phosphoric Acid 40% Solution,Phosphoric Acid 50%,Phosphoric Acid 60%,Phosphoric Acid 70%,Phosphoric Acid 80%,Phosphoric Acid 90%,Potassium Hydroxide 50%,Sodium Bicarbonate 10%,Sodium Bisulfate,Sodium Bisulfite,Sodium Hydroxide,Sodium Hydroxide 20%,Sodium Hypochlorite 10%,Sodium Hypochlorite 5%,Sulfuric Acid 10%,Sulfuric Acid 20%,Sulfuric Acid 30%,Sulfuric Acid up to 10%,Turpentine,Water
- Media Temperature (Maximum)
- 104 Degrees F
- Nameplate Voltage
- 120V AC
- Head Material
- Polycarbonate
- Seal Material
- Santoprene
- Duty Cycle
- Continuous
- Intake Connection Type
- NPT
- Motor Enclosure
- Totally Enclosed
- Frequency
- 60 Hz
- Motor Type
- Brushed DC
- Viscosity (Maximum)
- 100 cps
- Housing Material
- Polycarbonate
- Motor Enclosure Design
- Totally Enclosed
- Seal Type
- O-Ring
- Pump Technology
- Peristaltic
- Motor Thermal Protection
- Auto
