MFR # S3001AA101NG1
Zoro # G6411855
UPC # -
Country of Origin United States
Chemical Metering Pump Type Peristaltic
Flow Rate Output Control Variable
Max. Flow (gpd) - Pumps 5.00 gpd
Max. Flow (GPD) - Pumps 5.00 gpd
Voltage 120V
Max. Pressure - Pumps 100 psi
Voltage - Pumps 120V AC
Phase - Pumps 1
Max. Viscosity - Pumps 1,500 cps
HP - Pumps 1/16 hp
Turn Down Ratio - Pumps 100:1
Reproducibility - Pumps +/-2.0%
Self-Priming Yes
Features 7 days/24 hr Timer, Analog/Digital inputs/outputs, Leak Detect, Multiple Operation Modes, Performance Indicators, Tube Change
Tubing Material Santoprene
Max. Pressure 100 psi
Pump Type Peristaltic
Motor RPM 2,800 RPM
Number of Feeds 1
Includes 20 ft Roll of Suction/Discharge Tubing, Pump Tube, Duckbill Check Valve, Weighted Suction Line Strainer, (3) 1/4 in Connecting Nuts, (3) 1/4 in Ferrules
Flow Rate 0.003 gpm/0.013Lpm
Standards CE, cULus, NSF/ANSI 50, NSF/ANSI 372, NSF/ANSI 61
Max. Viscosity 1500 CPS
Turn Down Ratio 100:1
Motor HP 1/16 hp
Item - Chemical Metering Pumps Chemical Metering Pump
Phase Single
Item Peristaltic Chemical Metering Pump
Hz 60 Hz
Body Material Polycarbonate
Tubing Material - Peristaltic Pumps Santoprene
Seals and O-Rings - Pumps Santoprene
Min. Flow Rate 0.05 gpd
Head and Fitting Material - Pumps Polycarbonate/Polypropylene/PVC
Pump RPM 45 RPM
Reproducibility +/-2.0%
Suction Lift 25 ft
Degassing Valve Included No
Viscosity (Maximum) 1,500 cps
Frequency 60 Hz
Media Temperature (Maximum) 104 Degrees F
Motor Type Brushless DC
Discharge Connection Type NPT
Motor Speed (Maximum) 45 RPM
Pressure (Maximum) 100 psi Chemical Compatibility
See full list of Chemical Compatibility Acetic Acid 20%,Ammonium Hydroxide,Beer Yeast,Calcium Chloride,Caustic (Sodium Hydroxide),Chromic Acid 10%,Chromic Acid 30%,Chromic Acid 5%,Chromic Acid 50%,Citric Acid 50%,Ethyl Acetate,Ethylene Glycol,Formaldehyde,Formaldehyde 40%,Glucose,Glycerin,Hydrochloric Acid 10%,Hydrochloric Acid 20%,Hydrochloric Acid 30%,Hydrochloric Acid 37%,Hydrofluoric Acid 20%,Hydrofluoric Acid 75%,Muriatic Acid,Nitric Acid 10% Solution,Nitric Acid 20% Solution,Phosphoric Acid 100%,Phosphoric Acid 40%,Phosphoric Acid 40% Solution,Phosphoric Acid 50%,Phosphoric Acid 60%,Phosphoric Acid 70%,Phosphoric Acid 80%,Phosphoric Acid 90%,Potassium Hydroxide 50%,Sodium Bicarbonate 10%,Sodium Bisulfate,Sodium Bisulfite,Sodium Hydroxide,Sodium Hydroxide 20%,Sodium Hypochlorite 10%,Sodium Hypochlorite 5%,Sulfuric Acid 10%,Sulfuric Acid 20%,Sulfuric Acid 30%,Sulfuric Acid up to 10%,Turpentine,Water
Intake Connection Type NPT
Priming Self-Priming
Seal Material Santoprene
Duty Cycle Continuous
Ambient Temperature (Maximum) 104 Degrees F
Horsepower (Maximum) 1/16 hp
Flow Rate (Maximum) 5 gpd
Housing Material Polycarbonate
Motor Enclosure Totally Enclosed
Media Temperature (Minimum) 32 Degrees F
Fitting Material Polypropylene/PVC
Nameplate Voltage 120V AC
Control Programs 4-20 mA Input, 7 Day/24 Hour Timer, Cycle Timer, Hall Effect Flow Sensor, Manual Control
Head Material Polycarbonate
Flow Rate (Minimum) 0.05 gpd
Roller Material Polyethylene
Electrical Connection Type Plug-In
Motor Mounting Type Horizontal, Vertical
Motor Enclosure Design Totally Enclosed
Pump Technology Peristaltic
Motor Thermal Protection Auto
Seal Type O-Ring
