  11. Triangle Turning Insert, Triangle, 3/8 in, TNGA, 0.0468 in, CBN
Sumitomo Triangle Turning Insert, Triangle, 3/8 in, TNGA, 0.0468 in, CBN 6NCTNGA333-BNC300 - main

Triangle Turning Insert, Triangle, 3/8 in, TNGA, 0.0468 in, CBN

  • Mfr # 6NCTNGA333-BNC300

  • Zoro # G6370677

product price: $179.99
/ea
Free Shipping & Returns

Key Features

Insert Shape
Triangle
Insert Style
TNGA
Inscribed Circle
3/8 in
Insert Size
333
Chip-Breaker
No
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6NCTNGA333-BNC300
Zoro #
G6370677
UPC #
-
Country of Origin
Multiple

Dimensions

Insert Size
333
Corner Radius
0.0468 in
Mounting Hole Dia.
0.150"
Insert Thickness
0.1875"
Nose Radius
0.0469"
Depth of Cut
0.0150 in
Thickness
0.1875 in
Through Hole Inside Dia.
0.15 in

Details

Item
Triangle Turning Insert
Insert Shape
Triangle
Insert Style
TNGA
Inscribed Circle
3/8 in
Chip-Breaker
No
Grade
BNC300
Insert Material
CBN
Insert Application
Finishing
Rake
Negative
ISO Number
6NC-TNGA160412
Non Ferrous (N) Compatibility
No
Cast Iron (K) Compatibility
Yes
Coating
CVD
Super Alloy (S) Compatibility
No
No. of Edges
6
Workpiece Compatibility
Cast Iron (K), Hardened (H), Steel (P)
Steel (P) Compatibility
Yes
Cutting Direction
Neutral
Mounting Style
Top and hole Clamping
ANSI Number
6NCTNGA333-BNC300
For Use With
Toolholders, Boring Bars
Hardened (H) Compatibility
Yes
Stainless (M) Compatibility
No
Primary Material Application ISO Code
H
Coating Process
CVD
Included Angle
60 Degrees
Cutting Application
Turning
Insert Holding Type
Straight Hole
Shape
Triangle
Finish - Machining
TiN
Cutting Material Coverage
Mini Tip
Material - Machining
CBN
Primary Material Application
Hardened Steel
Manufacturer Grade
BNC300
Clearance Angle
0 Degrees
ANSI Code
6NC-TNGA333
Measurement System
Fractional Inch
Material
CBN

Description

Triangle Turning Insert, Inscribed Circle 3/8 in, TiN
