Telemecanique Sensors 2NC/2NO Limit Switch Body Nema 1, 2, 4, 6, 6P, 12, 13 9007CO66 - main

2NC/2NO Limit Switch Body Nema 1, 2, 4, 6, 6P, 12, 13

  • Mfr # 9007CO66

  • Zoro # G1926951

product price: $227.99
/ea
Free Shipping & Returns

Key Features

For Use With
Type 9007 C Standard Limit Switches
Standards
CE, CSA, UL Listed
Operating Temp.
0 Degrees to 185 Degrees F
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
AC Contact Rating
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9007CO66
Zoro #
G1926951
UPC #
785901032137
Country of Origin
Mexico

Dimensions

Depth
1.79 in
Width
1.55 in
Height
3.14-3.14 in
Overall Height
3.14 in
Overall Depth
1.79 in
Overall Width
1.55 in
Mounting Hole Diameter
0.2 in
Manufacturer Warranty Length
18 mo

Details

Item
Limit Switch Body
For Use With
Type 9007 C Standard Limit Switches
Standards
CE, CSA, UL Listed
Operating Temp.
0 Degrees to 185 Degrees F
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
AC Contact Rating
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
IP Rating
IP67
Contact Form
2NO/2NC
DC Contact Rating
0.11 A @ 250 V, 0.55 A @ 125 V
Body Material
zinc
Material
Zinc
Switch Function
2 SPDT-DB
Mechanical Durability
10000000 cycles
Electrical Durability
1000000 cycles
Shock Resistance
60 gn 9 ms IEC 60068-2-27
Vibration Resistance
25 gn 10-150 Hz)IEC 60068-2-6
Indicating Light
No Indicating Light Included
Operating Temperature - Minimum
-20 Degrees F
Compatible with Series
9007C
Body Configuration
Plug-In
Mounting Hole Vertical Center to Center Distance
60 mm
NEMA Enclosure Rating
1, 12, 13, 2, 4, 6, 6P
Operating Temperature - Maximum
185 Degrees F
Mounting Hole Horizontal Center to Center Distance
30 mm
Number of Mounting Holes
2
Ambient Air Temperature For Operation
-20-185°F standard environment
[Ui] Rated Insulation Voltage
600 V 3)UL 508 contact block || 600 VCSA C22.2 No 14
Product Compatibility
9007C
Terminals Description Iso N°1
(7-8)NO || (1-2)NC || (3-4)NO || (5-6)NC
Associated Head
9007C
Associated Connection Component
9007CT62
Protective Treatment
epoxy powder coat
Ambient Air Temperature For Storage
-20-185°F
Product Or Component Type
limit switch plug-in unit
Environmental Characteristic
standard environment
Number Of Steps
2
Body Type
standard plug-in
Device Short Name
9007C
Contacts Material
silver contacts
Function Available
2 stages sequential
Electrical Shock Protection Class
class 0 IEC 61140
Contact Operation
snap action
[Ithe] Conventional Enclosed Thermal Current
10 A
[Uimp] Rated Impulse Withstand Voltage
2.5 kV AC 1 min CE || 2.2 kV AC 1 min UL
Ip Degree Of Protection
IP67 conforming to IEC 60529
[Ie] Rated Operational Current
1.2 A 600 V AC, A600 NEMA rating designation || 1.5 A 480 V AC, A600 NEMA rating designation || 3 A 240 V AC, A600 NEMA rating designation || 6 A 120 V AC, A600 NEMA rating designation || 0.11 A 250 V DC, R300 NEMA rating designation || 0.55 A 125 V DC, R300 NEMA rating designation
Short-Circuit Protection
10 A CC non-time delay
Series Name
heavy duty
Nema Degree Of Protection
NEMA 1 Nema type 250 || NEMA 2 Nema type 250 || NEMA 4 Nema type 250 || NEMA 6 Nema type 250 || NEMA 6P Nema type 250 || NEMA 12 Nema type 250 || NEMA 13 Nema type 250
Number Of Poles
2
Positive Opening
without
Contacts Type And Composition
2(NC-NO)

Description

Limit Switch Body, Contact Form 2NO/2NC, For Use With Type 9007 C Standard Limit Switches, AC Contact Rating 1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V, NEMA Rating 1, 12, 13, 2, 4, 6, 6P, Electrical Connection Not Applicable, IP Rating IP67, Operating Temp. 0 Degrees to 185 Degrees F, Standards CE, CSA, UL Listed
