Telemecanique Sensors Cylindrical, Inductive Proximity Sensor, 17 mm Dia., Brass, 1/2 in Connector, 2 Wires, Shielded XS612B1MBU20 - main

Cylindrical, Inductive Proximity Sensor, 17 mm Dia., Brass, 1/2 in Connector, 2 Wires, Shielded

  • Mfr # XS612B1MBU20

  • Zoro # G0860119

product price:  $99.15
/ea

Key Features

Style
Cylindrical, Inductive
Measurement Range
2.5 to 4 mm
Proximity Sensing Method
Inductive
Body Material
Brass
Proximity Sensor Power Requirement
24 to 240V AC/DC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
XS612B1MBU20
Zoro #
G0860119
UPC #
785901235040
Country of Origin
France

Dimensions

Overall Diameter
17 mm
Length
61 mm
Overall Height
61 mm

Details

Item
Proximity Sensor
Style
Cylindrical, Inductive
Measurement Range
2.5 to 4 mm
Proximity Sensing Method
Inductive
Body Material
Brass
Proximity Sensor Power Requirement
24 to 240V AC/DC
Electrical Connection
1/2 in Connector
Output Circuit Type
AC/DC-Type
Output Circuit Number of Wires
2
Sensing Face Shielding
Shielded
Sensing Distance - Maximum
4 mm
AC Voltage Rating
24-240V AC
DC Voltage Rating
24-240V DC
Output Circuit Contact Form
NC
Standards
CE, CSA, UL Listed
Proximity Sensor Electrical Connection
Male Connector 1/2"20 UNF, 3 Pins
Proximity Sensor Operating Frequency
Less than Or Equal to 1000 Hz DC; Less than Or Equal to 25 Hz AC
IP Rating
IP67, IP69K
Description/Special Features
Frontal Detection Face; Output State 1 LED Yellow
Operating Temp. Range
-25 to 70 Degrees C
Features
Flush Mountable
Application
general purpose
Storage Temp. Range
-40-85 °C
Maximum Delay Recovery
0.2 ms
Maximum Voltage Drop
<5.5 V closed)
Series
XS6
Switching Capacity
5...200 mA AC/DC
Maximum Delay Response
0.5 ms
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Body Type
fixed
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Supply Voltage Limits
20-264 V AC/DC
Maximum Delay First Up
20 ms
Differential Travel
1...15% of Sr
Number of Pins
3
Switching Frequency
1,000 Hz (DC), 25 Hz (AC)
Electrical Installation Type
Direct Connector
Sensing Distance - Minimum
3 mm
Operating Temperature - Maximum
158 Degrees F
Body Finish
Nickel Plated
Includes Indicator Lights
Indicator Lights Included
Operating Temperature - Minimum
-13 Degrees F

Description

Inductive Cylindrical Proximity Sensor, IP Rating IP67, IP69K, Standards CE, CSA, UL Listed
