  11. Cylindrical, Inductive Proximity Sensor, 30 mm Dia., PPS, 2 m, Bare Wire, 2 Wires, Unshielded
Telemecanique Sensors Cylindrical, Inductive Proximity Sensor, 30 mm Dia., PPS, 2 m, Bare Wire, 2 Wires, Unshielded XS4P30MB230 - main

Cylindrical, Inductive Proximity Sensor, 30 mm Dia., PPS, 2 m, Bare Wire, 2 Wires, Unshielded

  • Mfr # XS4P30MB230

  • Zoro # G6209323

product price: $114.99
/ea
Free Shipping & Returns

Key Features

Measurement Range
0 to 12 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
24 to 240V AC/DC
Length
41 mm
Depth
30 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XS4P30MB230
Zoro #
G6209323
UPC #
785901316473
Country of Origin
France

Dimensions

Length
41 mm
Depth
30 mm
Overall Height
62 mm
Overall Diameter
30 mm
Cable Length
2 m

Details

Item
Inductive Cylindrical Proximity Sensor
Measurement Range
0 to 12 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
24 to 240V AC/DC
Proximity Sensor Electrical Connection
2m Cable
Proximity Sensor Operating Frequency
25 Hz AC/1000 Hz DC
Operating Temp. Range
-13 Degrees to 158 Degrees F
Description/Special Features
Yellow LED Output Indication
Max. Current Load
200mA
IP Rating
IP68
Standards
CCC, CE, CSA, Ecolab, RoHS, UL Listed
Electrical Connection
Bare Wire
Maximum Delay Response
0.2 ms
Storage Temp. Range
-40-85 °C
Maximum Delay Recovery
0.4 ms
Application
general purpose
Differential Travel
1...15% of Sr
Body Type
fixed
Switching Capacity
5...200 mA DC || 5...300 mA AC
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Series
XS4
Maximum Voltage Drop
<5.5 V closed)
Maximum Delay First Up
40 ms
Supply Voltage Limits
20-264 V AC/DC
Output Circuit Type
AC/DC-Type
Includes Indicator Lights
Indicator Lights Included
Output Circuit Number of Wires
2
Operating Temperature - Maximum
158 Degrees F
Sensing Face Shielding
Unshielded
Body Material
PPS
Body Finish
Nickel Plated
Switching Frequency
1,000 Hz (DC), 25 Hz (AC)
Output Circuit Contact Form
NC
Operating Temperature - Minimum
-13 Degrees F
DC Voltage Rating
24-240V DC
Sensing Distance - Maximum
15 mm
Electrical Installation Type
Prewired Cable
Load Current - Maximum
300 mA
AC Voltage Rating
24-240V AC
Style
Cylindrical, Inductive

Description

Inductive Cylindrical Proximity Sensor, Inductive, 30 mm, Proximity Sensor Power Requirement 24 to 240V AC/DC, Unshielded, Proximity Sensor Operating Frequency 25 Hz AC/1000 Hz DC, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 15 mm, Proximity Sensor Electrical Connection 2m Cable, Output Mode NC, IP Rating IP68, Case Material PPS, Length 41 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
