Hazardous Location Limit Switch, Wobble Stick, 2NC/2NO, 10A at 600V AC, Actuator Location: Top

  • Mfr # 9007CR61D

  • Zoro # G1683026

product price:
$
691.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Wobble Stick
Actuator Style - Limit Switch
Wobble Stick
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 600V
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
9007CR61D
Zoro #
G1683026
UPC #
785901861669
Country of Origin
Multiple

Dimensions

Actuator Length - Limit Switch
0.95 in
Roller Width
0.12 in
Roller Dia.
0.63 in
Actuator Length
0.95"
Body Depth - Limit Switch
2.08 in
Depth
2.08"
Body Width - Limit Switch
2.72 in
Height
6.10"
Body Height - Limit Switch
4.25 in
Width
2.72"
Roller Diameter
0.63 in
Manufacturer Warranty Length
18 mo
Body Width
2.72 in
Overall Width
2.72 in
Overall Depth
2.08 in
Body Depth
2.08 in
Overall Height
7.05 in
Mounting Hole Diameter
0.2 in
Body Height
4.25 in

Details

Item
Hazardous Location Limit Switch
Basic Actuator Style - Limit Switch
Wobble Stick
Actuator Style - Limit Switch
Wobble Stick
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 600V
DC Contact Rating - Limit Switch
10A at 600V
Body Style - Limit Switch
Standard
Mounting - Limit Switch
Surface
NEMA Rating
1, 12, 13, 2, 4, 6, 6P, 7, 9
Amps
10
Certification
UL Class I Groups B, C, D and Class II Groups E, F, G
Actuator Style (Limit Switch)
Wobble Stick
Body Material
Aluminum
AC Contact Rating
10 A @ 600 V
Standards
CSA C22.2 No.14, UL 508
Wiring Entry
1/2 in NPT
Contact Form
2NO/2NC
Mounting Hole Pattern - Limit Switch
2 Hole Diagonal
Movement
Horizontal
Basic Actuator Style (Limit Switch)
Wobble Stick
Boot Sealed Actuator (Limit Switch)
No
Travel
0.25 in
Limit Switch Style
Hazardous Location Limit Switch
Mounting Hole Spacing - Limit Switch
2.35 in x 1.17 in
Boot Sealed Actuator - Limit Switch
No
Actuator Location
Top
Operating Temp. Range
0 Degrees to 185 Degrees F
IP Rating
IP67
Mounting Hole - Limit Switch
(2) 0.20 in dia
Roller Material
Steel
Voltage Rating
600VAC/DC
Actuator Location (Limit Switch)
Top
Electrical Connection
Screw Terminal
Body Style (Limit Switch)
Standard
Stem Thread - Limit Switch
No Stem
Actuator Style
Roller Plunger
Contact Form - Limit Switch
2NC/2NO
DC Contact Rating
10 A @ 600 V
Series
9007CR
Operating Force
4.0 in-lb
Special Features
lateral approach, 2 directions
Head Material
zinc
Contact Material
silver contacts
Short Circuit Protection
10 A CC non-time delay
Actuation Type
by 30° cam
Contact Action
snap action
Vibration Resistance
25 gn 10-150 Hz)IEC 60068-2-6
Head Type
plunger head
Shock Resistance
60 gn 9 ms IEC 60068-2-27
Electrical Durability
1000000 cycles
Weight
2.5 lb(US)
Mechanical Durability
10000000 cycles
Mounting Hole Horizontal Center to Center Distance
30 mm
Operating Temperature - Minimum
-20 Degrees F
Boot Sealed Actuator
No Boot Included
Operating Force - Maximum
3 lbf
Hazardous Location Specification
Class I, Div 1, Group B, C, D, Class II, Div 1, Group E, F, G
Number of Mounting Holes
2
Resistance Properties
Shock Resistant, Vibration Resistant
Directional Movement
Linear
Mounting Style
Surface
Mounting Hole Vertical Center to Center Distance
60 mm
Operating Temperature - Maximum
185 Degrees F
NEMA Enclosure Rating
1, 12, 13, 2, 4, 6, 6P
Pretravel
0.08 in
Type Of Operator
steel spring return roller plunger
Number Of Poles
2

Description

Limit Switch, Actuator Style - Limit Switch Wobble Stick, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 10A @ 600V, DC Contact Rating - Limit Switch 10A @ 600V, Contact Form- Switches 2NC/2NO, Actuator Length - Limit Switch 0.95 in, Body Height - Limit Switch 4.25 in, Body Width - Limit Switch 2.72 in, Body Depth - Limit Switch 2.08 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Standard, NEMA Rating 1, 12, 13, 2, 4, 6, 6P, 7, 9
