  15. Heavy Duty Limit Switch, Plunger, Roller, 2NC/2NO, 10A at 600V AC, Actuator Location: Side
Telemecanique Sensors Heavy Duty Limit Switch, Plunger, Roller, 2NC/2NO, 10A at 600V AC, Actuator Location: Side 9007C62F - main

Heavy Duty Limit Switch, Plunger, Roller, 2NC/2NO, 10A at 600V AC, Actuator Location: Side

  • Mfr # 9007C62F

  • Zoro # G2399433

product price: $316.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A at 600V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9007C62F
Zoro #
G2399433
UPC #
785901500759
Country of Origin
Mexico

Dimensions

Body Width - Limit Switch
0.83 in
Roller Width
0.13 in
Height
4.02"
Actuator Length - Limit Switch
1.08 in
Depth
1.79"
Body Height - Limit Switch
2.5 in
Roller Dia.
0.63 in
Body Depth - Limit Switch
1.14 in
Width
1.55"
Actuator Length
1.08"
Overall Depth
2.63 in
Roller Diameter
0.63 in
Mounting Hole Diameter
0.2 in
Body Height
2.5 in
Overall Width
1.55 in
Manufacturer Warranty Length
18 mo
Body Depth
1.14 in
Body Width
0.83 in
Overall Height
4.02 in

Details

Item
Heavy Duty Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A at 600V
DC Contact Rating - Limit Switch
10A at 600V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Surface
Mounting Hole Spacing - Limit Switch
2.35 in x 1.17 in
Travel
0.25 in
Movement
Vertical
Operating Force
4.0 in-lb
Stem Thread - Limit Switch
No Stem
DC Contact Rating
10A at 600V
Actuator Style
Plunger
Limit Switch Style
Heavy Duty Limit Switch
Actuator Location
Side
Series
9007C
Boot Sealed Actuator - Limit Switch
No
Wiring Entry
1/2 in NPT
Actuator Style (Limit Switch)
Plunger, Roller
Roller Material
Steel
IP Rating
67
Body Material
Zinc
Body Style (Limit Switch)
Miniature
Basic Actuator Style (Limit Switch)
Plunger
Contact Form
2NC/2NO
Contact Form - Limit Switch
2NC/2NO
Mounting Hole - Limit Switch
(2) 0.20 in dia
Boot Sealed Actuator (Limit Switch)
No
Electrical Connection
Screw Terminals
Voltage Rating
600VAC/DC
Actuator Location (Limit Switch)
Side
Standards
CE, CSA, UL
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
Mounting Hole Pattern - Limit Switch
2 Hole Diagonal
Amps
10
Operating Temp. Range
0 Degrees to 185 Degrees F
AC Contact Rating
10A at 600V
Head Material
zinc
Contact Material
silver contacts
Differential Travel
0.03 in
Special Features
vertical approach, 2 directions
Mechanical Durability
10000000 cycles
Electrical Durability
1000000 cycles
Vibration Resistance
25 gn 10-150 Hz)IEC 60068-2-6
Shock Resistance
60 gn 9 ms IEC 60068-2-27
Weight
1.25 lb(US)
Actuation Type
by 30° cam
Contact Action
snap action
Short Circuit Protection
10 A CC non-time delay
Head Type
plunger head
Number of Mounting Holes
2
Plunger Adjustability
Adjustable
NEMA Enclosure Rating
1, 12, 13, 2, 4, 6, 6P
Body Configuration
Plug-In
Pretravel
0.08 in
Operating Temperature - Maximum
185 Degrees F
Directional Movement
Linear
Mounting Hole Horizontal Center to Center Distance
30 mm
Resistance Properties
Shock Resistant, Vibration Resistant
Operating Force - Maximum
4 lbf
Operating Temperature - Minimum
-20 Degrees F
Total Travel
0.25 in
Mounting Style
Surface
Boot Sealed Actuator
No Boot Included
Mounting Hole Vertical Center to Center Distance
60 mm
Type Of Operator
steel spring return side roller plunger with vertical roller vertical convertible to horizontal)
Number Of Poles
2

Description

Plug-In Limit Switch, Actuator Style - Limit Switch Plunger, Roller, Actuator Location - Limit Switch Side, AC Contact Rating - Limit Switch 10A @ 600V, DC Contact Rating - Limit Switch 10A @ 600V, Contact Form- Switches 2NC/2NO, Actuator Length - Limit Switch 1.08 in, Body Height - Limit Switch 2.5 in, Body Width - Limit Switch 0.83 in, Body Depth - Limit Switch 1.14 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 13, 2, 4, 6, 6P
