Shop TELEMECANIQUE SENSORS

Pressure Switch, Standard, SPDT, 1 Ports, 1/4-18" FNPT, 20 to 675 psi Range, Plastic

  • Mfr # 9012GPG2

  • Zoro # G3202412

product price:  $465.99
/ea
Free Shipping & Returns

Key Features

Action
Standard
Contact Form
SPDT
Number of Pressure Connection Ports
1
Pressure Connection Type
1/4-18" FNPT
Range
20 to 675 psi
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
9012GPG2
Zoro #
G3202412
UPC #
785901476474
Country of Origin
Mexico

Dimensions

Manufacturer Warranty Length
18 mo
Overall Height
6.84 in
Overall Width
2.21 in
Overall Depth
2.75 in

Details

Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Number of Pressure Connection Ports
1
Pressure Connection Type
1/4-18" FNPT
Range
20 to 675 psi
Housing Material
Plastic
Factory On Setting
20 psi
Factory Off Setting
675 psi
Standards
CE, CSA C22.2, RoHS, UL 508
AC Contact Rating
10A @ 480V
Ambient Temp. Range
-10 Degrees to 185 Degrees F
Series
9012G
DC Contact Rating
0.11A @ 250V, 0.22A @ 125V
Actuation Type
Diaphragm
Pressure Switch Port Type
1-Port 1/4-18 in FNPT
Temp. Range
-10 to 185 °F
Pressure Switch Differential
19 to 58.8 psi
Pressure Switch Range
20 to 675 psi
IP Rating
54
Max. Pressure
2000 psi
Pressure Switch Electrical Contact Form
SPDT
Electrical Connection
Screw-Clamp Terminals
Special Features
Mercury Free; Green Premium product
Material
Thermoplastic
Pressure - Minimum
90 psi
Proof Pressure
2,000 psi
Media Temperature - Maximum
250 Degrees F
Media Temperature - Minimum
-40 Degrees F
Pressure - Maximum
2,900 psi
Differential Pressure - Minimum
19 psi
Deadband Adjustability
Adjustable
Differential Pressure - Maximum
98 psi
Operating Temperature - Maximum
185 Degrees F
NEMA Enclosure Rating
1
Operating Temperature - Minimum
-10 Degrees F

Description

Pressure Switch, NEMA Rating 1, Series 9012G, Temp. Range -10 Degrees to 185 Degrees F, Standards CE, CSA C22.2, RoHS, UL 508, Special Features Nitrile (Buna-N) Diaphragm, Control Circuit Rated, Single Stage Switch, General Purpose (Indoor) Enclosure, AC Contact Rating 3 A @ 120 V, 3 A @ 240 V
