- Item
- Power Strip
- Type
- Surge
- Total Number of Outlets
- 8
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Black
- Gauge/Conductor
- 14/3
- Standards
- Approvals RoHS; cUL / CSA (Canada); FCC Part 68 (Communications); Industry Canada (Communications); UL1363 (Power Tap); UL1449 3rd Edition (AC Suppression); UL497A (Communications)
- Coax Surge Protection
- Yes
- Footnotes
- 1,2,3,4,6
- Medical Grade
- No
- Circuit Breaker
- 1
- Hz
- 50/60 Hz
- Outlet Center Distance
- 28.5mm Standard and 57mm Transformer
- Housing Material
- Plastic
- Telephone/Fax Surge Protection
- Yes
- NEC Cord Designation
- SJT
- Mounting Style
- Keyhole
- NEMA Receptacle Configuration
- NEMA 5-15R
- Power Indicator
- Yes
- Max. Amps
- 15A
- Communication Port
- (2) Coaxial, (2) RJ11 Telephone, (2) RJ45 Network
- For Use With
- and More, Audio/Visual Devices, Cad/Cam/Cae Workstations, Fileservers, Modems, Network Nodes, Personal Computers, Point-Of-Sale Terminals
- Rated Joules
- 3,240
- Voltage
- 120VAC
- Number of Transformer Outlets
- 3
- Number of Outlets
- 8
- NEMA Plug Configuration
- NEMA 5-15P
- Max. Surge Current
- 216 kA
- Includes
- 6 ft Coax Cable, 6 ft Network Cable, 6 ft Telephone Cord, Instruction Manual with Warranty Information
- Noise Attenuation
- Up to 40dB
- Number of Outlet Rows
- 2
- Outlet Surge Protection
- Yes
- Medical Facility Use
- Outside Patient Care Areas (UL 1363)
- Number of Conductors
- 3
- Application
- Home and Office
- USB Charging Port
- 0
- Plug Style
- Right-Angle Plug
- Trade Designation
- SJT
- Frequency
- 50/60 Hz
- Features
- Audible Alarm, Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Maximum Line Current
- 15 A
- Surge Energy Rating
- 3240 J
- Output Voltage
- 120 V AC
- Dataline Protection
- Fax/Modem/Phone, Network, Cable TV/Satellite
- Compatibility
- Computer, Modem, CAD/CAM/CAE Workstations, Network Nodes, File Servers, Point-of-Sale Terminals, a, Audio/Visual Devices
- Input Voltage
- 120 V AC
- Package Contents
- 8-Outlet TV/Modem Surge Protector, 6-ft. Telephone Cord, 6-ft. Network Cable, 6-ft. Coax Cable, Instruction Manual with Warranty Information
- Certifications & Standards
- UL1449 (let through rating 330V), IEEE 587 Category A and B, FCC Part 68, UL497A, UL1363, cUL
- Power Handling
- 1800 VA
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Input Cord Details
- SJT
- Input Plug Features
- Right Angle (36D)
- Diagnostic LED(s)
- Yes
- Outlet Safety Covers Detail
- Includes built-in sliding outlet safety covers
- Frequency Compatibility
- 50 / 60 Hz
- Nominal Input Voltage(s) Supported
- 120V AC
- Output Receptacles
- (8) 5-15R
- Network (Ethernet) Protection
- Yes
- Maximum Surge Amps
- 216000
- AC Suppression Response Time
- < 1 ns
- Outlets Measurement (Center to Center)
- Distance between standard outlets = 28.5mm; Distance between transformer outlets = 57mm
- Diagnostic LED Details
- Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
- Circuit Breaker (amps)
- 15
- AC Suppression Joule Rating
- 3240
- Package Includes
- TLP810NET;6 ft. telephone cord;6 ft. network cable;6 ft. coax cable;Instruction manual with warranty information
- Mounting Holes or Slots
- Yes
- Outlet Orientation
- Single row of 5, plus a second row of 3 for transformer accommodation
- EMI / RFI Filtering
- Up to 40 dB
- Cable (Coax) Protection
- Yes
- Network Compatibility
- 100 Mbps (Fast Ethernet)
- Material of Construction
- Plastic
- Maximum Surge Current
- 216 kA
- Product Type
- Surge Protector Outlet Strip
- Maximum Current
- 15 A
- Medical Facility Use UL Rating
- UL 1363
- Rated Energy Absorption
- 3,240 J
- Number of Circuit Breakers
- 1
