UPS Type
Line Interactive
Output Voltage
110/115/120V
Backup Time (Half/Full Load)
13 min/4 min
Outlet Type
(2) Surge; (6) UPS/Surge
NEMA Plug Configuration
5-15P
Transfer Time
6 milliseconds typical (10 milliseconds max)
NEMA Receptacle Configuration
(8) 5-15R
Undervoltage Correction
Input voltages between 89 and 108 are boosted by 18%
Output Voltage Regulation (Battery Mode)
120V (±10%)
Cold Start (Startup in Battery Mode During a Power Failure)
Cold-start operation supported
Output Volt Amp Capacity (VA)
750
Communications Interface
USB (HID enabled)
Output Voltage Regulation (Line Mode)
120V (+6%/-12%)
UPS Certifications
Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
Audible Alarm
UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions
DC System Voltage (VDC)
12
AC Mode Efficiency Rating (100% Load)
>95%
Nominal Output Voltage(s) Supported
110V; 115V; 120V
Overvoltage Correction
Input voltages between 128 and 149 are reduced by 15%
Recommended Electrical Service
15A 120V
Full Load Runtime (min.)
4 min. (600w)
Output Watt Capacity (Watts)
600
Battery Replacement Description
Replaceable internal batteries (see manual)
Relative Humidity
0 to 90%, non-condensing
Communications Cable
USB interface cable included
PowerAlert Software
For local monitoring via the UPSâ„¢s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
Output AC Waveform (Battery Mode)
PWM sine wave
UPS AC Suppression Joule Rating
316
Voltage Regulation Description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 89 to 145
Rated input current (Maximum Load)
10A
Primary Form Factor
Desktop
Battery Access
Battery access door
UPS Input Connection Description
10A
Low Voltage Transfer to Battery Power (Setpoint)
89
Operating Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Battery Recharge Rate (Included Batteries)
8 hours (10% to 90%)
Half Load Runtime (min.)
13 min. (300w)
Front Panel LCD Display
Touchscreen LCD reports input voltage, output voltage, load percentage, battery charge percentage and overload status
Nominal Input Voltage(s) Supported
120V AC
UPS AC Suppression Response Time
Instantaneous
UPS Certification Details
UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; RETIE (Colombia)
Individually Controllable Load Banks
No
EMI / RFI AC Noise Suppression
Yes
WatchDog Compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
Storage Temperature Range
+5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius
High Voltage Transfer to Battery Power (Setpoint)
145
Installation Form Factors Supported with Included Accessories
Tower
AC Mode BTU / Hr. (Full Load)
145
Hot-Swap PDU options
PDUB15 (2U / 8 5-15R outlets)
Switches
Power off/on switch
High Availability UPS Features
Battery Independent Restart
