VA Rating - UPS Systems
3.0 kVA
UPS Type
Line Interactive
Output Voltage
110/115/120V AC
Backup Time (Half/Full Load)
9 min/3 min
Ports
DB9 Serial, EPO, USB
Automatic Volts Regulation
Yes
Special Features
Hot Swappable Batteries
NEMA Receptacle Configuration
(8) 5-15/20R; (1) L5-30R
Standards
CSA (Canada), ENERGY STAR Qualified, FCC Part 15 Class a (USA), ICES (Canada), NOM (Mexico), REACH, RoHS, UL1778
NEMA Plug Configuration
L5-30P
Fax/Modem Line Protection
No
Transfer Time
1 to 5 msec
Includes
(4) Post Rack Mount Installation Kits, PowerAlert Software with USB, Serial and EPO Cables
Capacity - Batteries
3000 VA/2250 W
Input Connection
NEMA L5-30P Plug
Storage Temperature Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
High Voltage Transfer to Battery Power (Setpoint)
145
LED Indicators
Network Link/Activity (Green): Flashes for network activity. Network Speed (Yellow): 10 Mbps (Flashing), 100 Mbps (On steady). LX Platform Interface Status: Normal Operation (Solid Green); Software Update (Alternating Green/Orange ~1/sec); Factory Reset (Alternating Green/Orange ~2/sec).
Nominal Output Voltage(s) Supported
110V; 115V; 120V
Front Panel LCD Display
Front panel LCD information and configuration screen offers detailed UPS and site power status and operating data, plus configuration of voltage, operating mode, alarm function and a variety of additional options (see manual for detailed LCD configuration and monitoring options)
Output kW Capacity (kW)
2.25
Operating Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Network Speed
10/100 Mbps
Full Load Runtime (min.)
3.5 min. (2250w)
WatchDog Compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
Rated input current (Maximum Load)
24A
UPS AC Suppression Response Time
Instantaneous
Undervoltage Correction
Input voltages between 108 and 96 are boosted by 12%
Half Load Runtime (min.)
10 min. (1125w)
Expandable Battery Runtime
Output with external battery pack configurations is limited to 1600 watts maximum
EPO Port
RJ11 interface jack with 4-meter cable included. Supports normally open and normally closed EPO systems
Severe Undervoltage Correction
Input voltages between 83 and 95 are boosted by 24%
Network Monitoring Port
RJ45 Network port, Micro-USB Configuration/Console port, USB A port supports a variety of Envirosense2 environmental and control modules. See Accessories>Management Hardware section for more information about these modules.
Network UPS Tools Compatibility
NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
Communications Cable
Micro-USB, USB, and DB9 cabling included
Output Voltage Regulation (Battery Mode)
+/- 5%
Communications Interface
(1) DB9 Serial; (1) EPO (emergency power off); (1) Micro-USB; (1) Pre-installed network card; (1) RJ45 Network; USB (HID enabled); (1) USB-A; (1) USB-B
Installation Form Factors Supported with Included Accessories
4 post 19 inch rackmount
Primary Form Factor
Rackmount
Battery Recharge Rate (Included Batteries)
Less than 4.5 hours from 10% to 90%
Network Monitoring Port Description
Includes pre-installed WEBCARDLX Network Management Card interface
High Availability UPS Features
Hot swappable batteries
EMI / RFI AC Noise Suppression
Yes
Included Mounting Accessory Description
Included 4POSTRAILKIT mounting bracket enables installation in 4 post racks from 20.5 to 36 inches (521 to 914mm)
Output Volt Amp Capacity (VA)
3000
Output Circuit Breakers
Two 20A output breakers protect 4 5-15/20R outlets each
Audible Noise
45 dBA maximum, front side 1m
UPS AC Suppression Joule Rating
570
Output Voltage Regulation (Line Mode)
-14%, +6%
Battery Mode BTU / Hr. (Full Load)
1356
AC Mode BTU / Hr. (Full Load)
189
Cold Start (Startup in Battery Mode During a Power Failure)
Cold-start operation supported
External Battery Pack Compatibility
BP48V24-2U (limit 1); BP48V60RT-3U (multi-pack compatible); BP48V27-2US (multi-pack compatible)
Internal UPS Replacement Battery Cartridge
RBC94-2U
Individually Controllable Load Banks
Yes
Grounding Lug
Includes back panel grounding lug
Output Watt Capacity (Watts)
2250
PowerAlert Software
For local monitoring via the UPSâ„¢s built-in Serial or USB communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert. LX Platform Interface: PowerAlert Device Manager 15 (PADM15)
UPS Certification Details
SAFETY STANDARD (U.S.) - UL1778:2014 (5th Ed) R10.17; SAFETY STANDARD (CANADA) - CAN/CSA-C22.2 No. 107.3-14 (3rd Ed) + GI1 / FCC/ICES COMPLIANT - CLASS A
Audible Alarm
Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions
AC Mode Efficiency Rating (100% Load)
0.98
Recommended Electrical Service
30A 120V
Low Voltage Transfer to Battery Power (Setpoint)
83
Nominal Input Voltage(s) Supported
120V AC
Switches
3 pushbutton switches control OFF / ON power status, MODE selection and MUTE / ENTER control functions. LX Platform Interface: Recessed reset switch for interface reboot and factory reset
Overvoltage Correction
Input voltages between 127 and 145 are reduced by 12%
Voltage Regulation Description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 145
Load Management Receptacles
Two switchable single-outlet load banks
Output kVA Capacity (kVA)
3
UPS Certifications
Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
Battery Replacement Description
Hot-swappable, user replaceable batteries
DC System Voltage (VDC)
48
Battery Access
Front panel battery access door
Alarm Cancel Operation
Power-fail alarm can be temporarily silenced using alarm-cancel switch; silent mode alarm configuration option available
Relative Humidity
0 to 95%, non-condensing
Output AC Waveform (Battery Mode)
Pure Sine wave
Installation Form Factors Supported with Optional Accessories
2 post rackmount ( 2POSTRMKITWM ); 2-4 post front rail rackmount ( UPSHDEARKIT ); 4 post rackmount short-depth ( 4POSTRAILKITWM ); Tower ( 2-9USTAND ); Wallmount ( 2POSTRMKITWM )
SNMP Compatibility
SNMP V1, V2c, V3
Software Included
PowerAlert Software
Package Contents
SMART3000RM2UN UPS System with Pre-installed WEBCARDLX, PowerAlert Software CD, USB Cable, Serial Cable, EPO Cable, 4 Post Installation Kit, Instruction Manual
Load Capacity
3000 VA/2250 W
Network Management
SNMP Manageable
Typical Battery Recharge Time
4.50 Hour
Operating Temperature - Maximum
104 Degrees F
Manufacturer Warranty
2 yr, 3 yr Registration
Run Time - Full Load
3 min
Plug Configuration
L5-30P
Receptacle Configuration
5-20R, L5-30R
Number of Outlets - UPS
7
Surge Suppression Rating
380 J
Power Rating - Real
2.25 kW
Data Line Protection
Includes Data Line Surge Protection
Input Current - Maximum
24 A
Number of Outlets - Surge Only
7
Output Ports Included
DB9 Serial, EPO, USB
External Battery Compatible
Not External Battery Pack Compatible
Transfer Time - Maximum
5 msec
Power Rating - Apparent
3 kVA
Includes Battery
Battery Included
Audible Alarm Conditions
Low Battery, Overload, Power Outage
Transfer Time - Minimum
1 msec
Battery Recharge Time
5 hr
Battery Chemistry
Valve Regulated Lead Acid
Automatic Voltage Regulation
Includes Automatic Voltage Regulation
Operating Temperature - Minimum
32 Degrees F
