  11. Male Disconnect, Yellow, 12-10AWG, PK10
Velvac Male Disconnect, Yellow, 12-10AWG, PK10 37487 - main

Male Disconnect, Yellow, 12-10AWG, PK10

  • Mfr # 37487

  • Zoro # G5367467

product price: $9.85
/pk 10, $0.99/ea

Key Features

Insulation
Full
Insulation Color
Yellow
Insulation Type
Heat Shrink
Wire Range
12 to 10 AWG
Connection Type
Crimp
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
37487
Zoro #
G5367467
UPC #
728974160697
Country of Origin
United States

Dimensions

Tab Size
0.032 in x 0.250 in
Overall Length
1.5 in
Barrel Inside Dia.
0.142 in
Minimum Wire Size
12 AWG
Tab Thickness
0.032 in
Barrel Inside Diameter
0.142 in
Maximum Wire Size
10 AWG
Tab Width
0.25 in

Details

Item
Male Disconnect
Insulation
Full
Insulation Color
Yellow
Insulation Type
Heat Shrink
Wire Range
12 to 10 AWG
Connection Type
Crimp
Seam
Brazed
Max. Voltage
600 V
Max. Temp.
221 Degrees F
Connection Material
Copper
Standards
UL Listed
Insulation Material
Nylon/Polyolefin
RoHS Compliant
Yes
Disconnect Style
Tab
Maximum Voltage
600 V
Maximum Operating Temperature
221 Degrees F
Terminal Type
Tab
Insulation Coverage
Full Coverage
Termination Style
Crimp
Barrel Style
Funnel Entry
Special Features
Adhesive Lining Which Blocks Out Water, Adds Tensile Strength and Strain Relief, CNS Extreme Waterproof Wire Terminals are Designed to Perform in the Harshest Environments, It Has a Triple Layer of Protection Around a 99.9% Copper Connector for Maximum Strength and Conductivity, Polyolefin Shrink Tubing Which Allows a Complete Environment and An Abrasion Resistant Seal
Seam Style
Butted
Minimum Operating Temperature
-40 Degrees F
Contact Finish
Tin
Contact Material
Copper

Description

Wire Disconnect, Contact Finish Tin, Contact Material Copper, Disconnect Style Quick Disconnect, Insulation Color Yellow, Insulation Coverage Full Coverage, Insulation Material Nylon with Heat Shrink, Maximum Temperature 221 Degrees F, Minimum Wire Size 12 AWG, Maximum Wire Size 10 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Tab, Termination Style Crimp, RoHS Compliant Yes, Seam Style Butted, Standards UL Listed, Barrel Inside Diameter 0.142 in
