Shop WEG

Explosion Proof Motor, Rigid Base

  • Mfr # 00218XT3E145TC
  • Zoro # G722935496
product price:
$
1,139.99
/ea
Free Shipping & Returns

Key Features

Frequency
60/50 Hz
Product Type
Explosion Proof Motor
Ambient Temperature - Maximum
40 Degrees C
Number of Speeds
1
Constant Torque Rating
20:1
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
00218XT3E145TC
Zoro #
G722935496
UPC #
7909323913512
Country of Origin
Mexico
Frequency
60/50 Hz
Product Type
Explosion Proof Motor
Ambient Temperature - Maximum
40 Degrees C
Number of Speeds
1
Constant Torque Rating
20:1
Application
Hazardous Location
Temperature Code
T3C
Variable Torque Rating
1000:1
Efficiency Rating
Premium Efficiency (IE3)
Full Load Current @ 60 Hz
5.6/2.8 A
NEMA Design Class
B
Explosion Rating
Explosion Proof
Motor Design
Three-Phase
Insulation Class
F
Nominal Efficiency
86.5 %
Usable @ 200V
Not Usable at 200V
Weight
73.2 lb
Phase
Three
Hazardous Location Division
Division I
Frame Material
Cast Iron
Bearing Protection Type
Shaft Slingers
Motor Enclosure Type
Totally Enclosed Fan Cooled
Bearing Type
Ball
Standards
cCSAus, UL Listed
Item
Explosion Proof Motor
Nameplate Service Factor @ 60 Hz
1.15
Inverter Rating
Inverter Rated
Hazardous Location Class
Class I, Class II
Duty Cycle
Continuous
Usable @ 208V
Not Usable at 208V

Description

Explosion Proof Motor, Three Phase, Motor Design Three-Phase, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Thermal Protection T-Stat, Hazardous Location Class Class I, Class II, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Hazardous Location Division Division I
