Shop WESTWARD

Jobber Drill Set, 3/8 Shank, 15 PC, HSS

  • Mfr # 5UDP1

  • Zoro # G2741392

product price:  $74.79
/ea

Key Features

Number of Pieces
15
Cutting Direction
Right Hand
Drill Bit Point Angle
135 Degrees
Drill Bit Material
High Speed Steel
Includes
Metal Drill Index
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
5UDP1
Zoro #
G2741392
UPC #
-
Country of Origin
United States

Dimensions

Shank Dia.
1/6 in
Drill Bit Dimension Type
Fractional Inch
Drill Bit Size
1/16 in to 1/2 in by 32nds
Sizes Included
1/16", 3/32", 1/8", 5/32", 3/16", 7/32", 1/4", 9/32", 5/16", 11/32", 3/8", 13/32", 7/16", 15/32", 1/2"
Depth x Dia. Ratio
4xD
Depth:Dia. Ratio
4xD
Drill Bit Sizes Included
1/16 in, 1/2 in, 1/4 in, 1/8 in, 11/32 in, 13/32 in, 15/32 in, 3/16 in, 3/32 in, 3/8 in, 5/16 in, 5/32 in, 7/16 in, 7/32 in
Overall Length
1 7/8 in, 2 1/4 in, 2 3/4 in, 3 1/8 in, 3 1/2 in, 3 3/4 in, 4 in, 4 1/4 in, 4 1/2 in, 4 3/4 in, 5 in, 5 1/4 in, 5 1/2 in, 5 3/4 in, 6 in
Largest Drill Bit Size
1/2 in
Smallest Drill Bit Size
1/16 in
Drill Length Class
Jobber-Length
Wire Rope Length
1 7/8 in, 2 1/4 in, 2 3/4 in, 3 1/8 in, 3 1/2 in, 3 3/4 in, 4 in, 4 1/4 in, 4 1/2 in, 4 3/4 in, 5 in, 5 1/4 in, 5 1/2 in, 5 3/4 in, 6 in

Details

Item
Jobber Length Drill Bit Set
Number of Pieces
15
Cutting Direction
Right Hand
Drill Bit Point Angle
135 Degrees
Drill Bit Material
High Speed Steel
Includes
Metal Drill Index
Point Type
Split Point
Drill Bit Grouping
Drill Bit Set
Standards
Not Rated
Finish - Machining
Black and Gold
Measurement System
Fractional Inch
Material - Machining
High Speed Steel
Primary Material Application
Aluminum, Cast Iron, Steel
Primary Material Application ISO Code
K, N, P
Spiral Direction
Right Hand
Flute Type
Spiral
Shank Type - Machining
Straight
Coolant Fed
Non-Coolant Through
Number of Flutes
2
Aircraft Drill
No
Number of Drill Bits
15
Drill Bit Point Type
Split Point
Drill Bit Case Type
Drill Index
Material Grade - Machining
Heavy Duty
Helix Angle - Minimum
21 Degrees
Helix Angle - Maximum
34 Degrees

Description

The WESTWARD - 5UDP1 is a 15-piece jobber length drill bit set made from high speed steel (HS S). It features split point, 135-degree point angle with a two-flute spiral design compatible with right-hand cutting direction (for right-hand spiral cutting). This set covers fractional inch sizes from 1/16 inch to 1/2 inch, with overall lengths range from 1 7/8 in to 6 in, for use on materials including aluminum, cast iron, and steel categorized as ISO codes K, N, and P. The drill bits include a metal drill index case for storage.

Key Features:

  • Drill bit sizes included: 1/16", 3/32", 1/8", 5/32", 3/16", 7/32", 1/4", 9/32", 5/16", 11/32", 3/8", 13/32", 7/16", 15/32", 1/2"
  • Jobber-length drill bits with overall lengths range from 1 7/8" to 6"
  • Material: Heavy duty high speed steel for machining
  • Point type: Split point with 135-degree angle for precise starts
  • Two-flute spiral design with helix angle between 21° and 34°
  • Shank diameter: 1/6 inch with straight shank type
  • Right-hand spiral, two-flute design
  • Comes with metal drill index case for storage
  • Not rated for aircraft or aerospace applications
