Indexable Profiling End Mill, VSM490-15 Series, High Speed Steel, 15.00mm Depth of Cut
Mfr # 5710525
Zoro # G3793524
product price:Â $1,139.99
/ea
Free Shipping & Returns
Key Features
Series
VSM490-15
Overall Length
50.01mm
Depth of Cut
15.00mm
Material - Machining
High Speed Steel
Insert Size
15T608
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
MFR #
5710525
Zoro #
G3793524
UPC #
4050841618816
Country of Origin
Multiple
Dimensions
Overall Length
50.01mm
Depth of Cut
15.00mm
Insert Size
15T608
Arbor Dia.
27.00mm
Hub Outside Dia.
60.00mm
Details
Item
Indexable Profiling End Mill
Series
VSM490-15
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
90 Degrees Rectangle Mill 4
Rake
-13.656 Degrees Radial, -8 Degrees Axial
Insert Style
XNGU SRMM
Features
Effective Internal Coolant Feature, Precisely Reaching the Cutting Edge, Stepless Solution, Strong Concept to Run up to 15mm (0.590 in) Depth of Cut, Superior Wall and Surface Finish Capabilities, True 90 Degrees to Run Precise Applications in Multiple Axial Passes
Max. Speed
12,300 RPM
Insert Holding Type
Screw
ISO Number
VSM490D080Z07S27XN15
Compatible Hardware
Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 Ip15, SHCS with Coolant Groove, Torx Plus Drive Wrench DT15IP
Number of Inserts
7
ANSI Code
VSM490D080Z07S27XN15
Coolant Fed
Coolant Through
Cutting Application
Face Milling, Pocketing, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End
Description
Indexable Profiling End Mill, Depth of Cut 15.00mm, Overall Length 50.01mm, ANSI Code VSM490D080Z07S27XN15, Compatible Hardware Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 Ip15, SHCS with Coolant Groove, Torx Plus Drive Wrench DT15IP, Coolant Fed Coolant Through, Cutting Application Face Milling, Pocketing, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End
