  5. High-Pressure Compressor Gauge, 0 to 3,000 psi, 1 1/2 in Dial, 1/8 in NPT, Bottom Location
Winters High-Pressure Compressor Gauge, 0 to 3,000 psi, 1 1/2 in Dial, 1/8 in NPT, Bottom Location PRL038 - main
Shop WINTERS

High-Pressure Compressor Gauge, 0 to 3,000 psi, 1 1/2 in Dial, 1/8 in NPT, Bottom Location

  • Mfr # PRL038

  • Zoro # G1605053

product price:  $31.39
/ea

Key Features

Accuracy
+/-2.50%
Process Connection Location
Bottom
Process Connection Size
1/8 in
Process Connection Type
NPT
Dial Size (In.)
1 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PRL038
Zoro #
G1605053
UPC #
628311278057
Country of Origin
China

Dimensions

Process Connection Size
1/8 in
Dial Size (In.)
1 1/2 in
Nominal Dial Size
1 1/2 in
Case Diameter
1.653 in
Case Depth
1 in
Manufacturer Warranty Length
5 yr
Nominal Dial Diameter
1 1/2 in

Details

Item
High-Pressure Compressor Gauge
Accuracy
+/-2.50%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Actuators, Regulators and Respirators, Valves
Gauge Case Material
304 Stainless Steel
Series
PRL
Lens Material
Acrylic
Primary Pressure Range
0 to 3,000
Primary Scale Units
psi
IP/NEMA Rating
IP52
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Gauge Primary Range Smallest Graduation
100/1000
Calibration Certificate Included
No
Gauge Special Options
Heavy Duty
For Use With
Media Compatible with 316L Stainless Steel
Connection Type
MNPT
Gauge Primary Range Numbered Graduations
500/4000
Socket Material
316 Stainless Steel
Smallest Graduation
50 psi/500 kPa
Gauge Secondary Range Values
0 to 20,000
Features
Small Diameter
Case Material
304 Stainless Steel
Case Color
Metallic
Standards
CRN Registered, RoHS
Includes Mounting Hardware
No
Sensor Material
316L Stainless Steel
Sensor Type
Bourdon Tube
Secondary Pressure Scale Color
Red
Over-Pressure Limit
25% of Full Scale
Scale Type
Dual
Secondary Pressure Range
0 to 20,000
Adjustable Pointer
No
Accuracy Grade
Not Graded
Pressure Range Type
Pressure
Process Temperature Range
-40 Degrees to 150 Degrees F
Pointer Color
Black
Pointer Material
Aluminum
Secondary Scale Units
kPa
Freeze Resistant Movement
No
Removable Bezel
No
Primary Scale Minor Graduations
100, 1,000
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F
Dial Face Material
Aluminum
Compatible Process Media
316L Stainless Steel
Process Connection Gender
Male
Case Construction
Welded Joint
Pressure Gauge Type
Commercial Pressure Gauge
Non-Sparking
No
Accuracy Scale
Full Scale
Dial Color
White
Cleaned for Oxygen Service
No
Movement Material
304 Stainless Steel
Primary Scale Numeric Increments
500, 4,000
Primary Pressure Scale Color
Black
Operating Temperature Range
-40 Degrees to 150 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 kPa
Primary Scale Pressure Measurement - Minimum
0 psi
NEMA Enclosure Rating
5
Includes Calibration Certificate
No
Primary Scale Color
Black
Process Media Temperature - Maximum
150 Degrees F
Primary Scale Pressure Measurement - Maximum
3,000 psi
Case Liquid
None
Secondary Scale Pressure Measurement - Maximum
20,000 kPa
Operating Temperature - Maximum
150 Degrees F
IP Rating
IP52
Process Media Temperature - Minimum
-40 Degrees F
Operating Temperature - Minimum
-40 Degrees F
Compatible with Brand
Universal
Field Fillable
No

Description

High-Pressure Compressor Gauge, Nominal Dial Size 1 1/2 in, Accuracy +/-2.50 Percent, Gauge Case Material 304 Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Acrylic, Process Connection Size 1/8 in, Field Fillable No, Process Connection Location Bottom, Case Color Metallic, IP/NEMA Rating IP52, Primary Pressure Range 0 to 3,000, Dial Color White, Pressure Gauge Type Commercial Pressure Gauge, Liquid-Filled Case No, Panel-Mountable No
