Shop All Fan and Limit Controls
Zoro Select

Adjustable Limit, Auto Reset, 210-290

original price: $13.69
10% off
new price: $12.29
/ea
Delivery to commercial address only
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Temp. Range (F) 210 to 290
  • Type Adjustable Limit, Automatic Reset
  • Switch Type SPST
  • Depth (In.) 1 3/4 in
  • Width (In.) 2 in
See all product information

Product Information

Dimensions

Depth (In.) 1 3/4 in
Width (In.) 2 in
Height (In.) 1 1/4 in
Mounting Hole Diameter 1/8 in
Mounting Base Width 1 3/4 in
Overall Width 2 in
Mounting Base Length 2 in
Terminal Size 1/4 in
Face Diameter 2 in
Overall Depth 1 3/4 in
Overall Height 1 1/4 in

Details

Item Temperature Limit Controller
Temp. Range (F) 210 to 290
Type Adjustable Limit, Automatic Reset
Switch Type SPST
Switch Closes @ (F) 210 to 250
Switch Opens @ (F) 250 to 290
Voltage Range 120 to 240
Resistive Amps @ 120V 25 A
Resistive Rating 240V 25
Pilot Duty Contacts (VA) 125 VA
Inductive Amps @ 120V 14 A
Inductive Amps @ 240V 10 A
Circuit #1 Switch Opens @ (F) 250 to 290
Circuit #1 Switch Closes @ (F) 210 to 250
Differential 40
Switch Action Open on Rise
Temperature Differential 40 Degrees F
Mounting Hole Center to Center Distance 1 5/8 in
Reset Type Automatic Reset
Wire Connections Spade Terminals
Weight 1 oz
Contact Form SPST
Pilot Contact Rating 125 VA
Product Type Temperature Limit Controller
Switch Opening Temperature 250 Degrees F, 290 Degrees F
Input Voltage 120V AC, 240V AC
Number of Mounting Holes 2
Resistive Amps @ 277V AC 25 A
Switch Closing Temperature 210 Degrees F, 250 Degrees F
Application Adjustable Limit Control
Mounting Surface Mount
Standards cULus Recognized
IP Rating Not Rated
Resistive Amps @ 120V AC 25 A
Resistive Amps @ 240V AC 25 A

Description

Temperature Limit Controller, Application Adjustable Limit Control, Mounting Surface Mount, Contact Form SPST, Switch Action Open on Rise, Reset Type Automatic Reset, Switch Closing Temperature 210 Degrees F, 250 Degrees F, Switch Opening Temperature 250 Degrees F, 290 Degrees F, Input Voltage 120V AC, 240V AC, Maximum Control Temperature Not Applicable, Minimum Control Temperature Not Applicable, Mounting Base Length 2 in, Mounting Base Width 1 3/4 in, Product Type Temperature Limit Controller
