Zoro Select Plate Caster, 125 lb. Ld Rating, Delrin P12S-R030D-12-WB - main

Plate Caster, 125 lb. Ld Rating, Delrin

  • Mfr # P12S-R030D-12-WB

  • Zoro # G1620444

product price:  $6.85
/ea

Key Features

Inside Bolt Hole Spacing
1-3/4 in x 2-13/16 in
Features
Noise Reduction
Non-Marking
No
Number of Wheels
1
Standards
ANSI ICWM, NSF Listed
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
P12S-R030D-12-WB
Zoro #
G1620444
UPC #
-
Country of Origin
China

Dimensions

Overall Height
4-1/4in
Wheel Width
1 1/4 in
Mounting Bolt Dia.
5/16 in
Wheel Dia.
3 in
Swivel Radius
2 7/8 in
Mounting Height
4 3/16 in
Mounting Plate Size
2-1/2in x 3-5/8in
For Axle Dia.
3/8 in
Overall Wheel Width
1 1/4 in
Mounting Plate Length
2 1/2 in
Outside Slot Spacing - Length
3.063 in
Mounting Plate Thickness
1/8in
Inside Slot Spacing - Length
2.813 in
Inside Slot Spacing - Width
1.75 in
Outside Slot Spacing - Width
1.75 in

Details

Inside Bolt Hole Spacing
1-3/4 in x 2-13/16 in
Features
Noise Reduction
Non-Marking
No
Number of Wheels
1
Standards
ANSI ICWM, NSF Listed
Thread Guards
No
Caster Brake Included
Yes
Wheel Color
Black
Frame Finish
Zinc Plated
Caster Brake Type
Side Brake
System of Measurement
Inch
Caster Temp. Range Available
Yes
Item
Swivel Caster with Brake
Caster Plate Hole Pattern
C
Application
Food Service Racks and Cases, Hospital Equipment, Hotel Equipment, Institutional Equipment, Laundry Trucks, Office Equipment, Stock Carts, Store Fixtures, Utility Carts
Includes
Strap Type Brake
Caster Frame Material
Steel
Extended Lead
No
Load Rating
125 lb
Caster Sub-Type
Swivel
Replacement Wheel
Mfr. No. P-R-030x013/038D
Core Color
Black
Outside Bolt Hole Spacing
1-3/4 in x 3-1/16 in
Load Rating Range
Light-Duty
Wheel Core Material
Rubber
Number of Mounting Holes
4
Swivel Construction
Kingpin
Wheel/Tread Hardness Rating
Soft
Tread Shape
Standard
Swivel Raceway Type
Double Ball
Wheel Bearing Type
Delrin
Includes Thread Guards
No
Swivel Lock Type
2-Position Directional Lock
Wheel/Tread Material
Rubber
Wheel/Tread Color
Black
Tread Color
Black
Tread
Standard
Caster Mounting Type
Plate
Resistant To
Chemical Resistance To Many Aggressive Substances, Except Oils
Series
P12 Series
Load Capacity
125 lb
ESD Conductive
No
Wheel Hardness Rating
80 Shore A
Compatible With
P-R-030X013/038D
Load Capacity - Maximum
300 lb
Mounting Hole Type
Slot
Mounting Plate Shape
Rectangle
For Surface Type
Asphalt, Ceramic, Grease, Rubber, Steel
Brake Location
Side
Wheel Bearing Material
Delrin
Wheel Core Type
Solid
Caster Features
Corrosion-Resistant
Operating Temperature - Minimum
-20 Degrees F
Operating Temperature Range
-20 Degrees To 125 Degrees F
Operating Temperature - Maximum
180 Degrees F

Description

Swivel, Plate Caster, Load Rating 125 lb, Swivel Lock Type 2-Position Directional Lock, Wheel Dia. 3 in, Wheel Width 1 1/4 in, Wheel/Tread Material Rubber, Wheel Core Material Rubber, Non-Marking No, Number of Wheels 1, Caster Brake Type Side Brake, Tread Shape Standard
