Apollo Valves Water Pressure Reducing Valve, 2 In. 36LF20801 - main

Water Pressure Reducing Valve, 2 In.

  • Mfr # 36LF20801

  • Zoro # G5274963

product price: $376.99
/ea
Free Shipping & Returns

Key Features

Pipe Size
2"
Inlet Size
2"
Connection Type
No Union NPT
Body Material
Lead Free Bronze
Max. Pressure
300 psig
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
36LF20801
Zoro #
G5274963
UPC #
670750650512
Country of Origin
United States

Dimensions

Pipe Size
2"
Inlet Size
2"
Height
11 1/2 in
Length
7 1/8 in
Overall Height
5 5/8 in
Outlet Connection Size
2 in
Inlet Connection Size
2 in
Overall Width
7 1/8 in

Details

Connection Type
No Union NPT
Body Material
Lead Free Bronze
Max. Pressure
300 psig
Max. Temp.
180 Degrees F
Item
Water Pressure Reducing Valve
Standards
ASSE 1003, CSA B356, NSF 372,ARRA
Material
Lead Free Bronze
Pressure Adjustment Range
5 to 75 psig
Application
Residential and Commercial Potable Water Distribution Systems
Preset Pressure Settings
50 psi
Strainer
No
Valve Type
Standard
Material of Construction
Lead Free Bronze
Connection
FNPT
Factory Set Pressure
50 psi
Seat Material
EPDM
Disc Material
EPDM
Pilot Adjustment - Maximum
75 psig
Inlet Connection Type
NPT
Operating Pressure - Maximum
300 psi
For Media
Water
Operating Pressure - Minimum
25 psi
Fluid Temperature - Maximum
180 Degrees F
Includes Strainer
Strainer Included
Outlet Connection Type
NPT
Flow Rate - Continuous Maximum
127 gpm
Coating/Lining
NSF Listed Fusion Bonded Epoxy Lining and Coating
Pilot Adjustment - Minimum
25 psig
Bonnet Material
Bronze
NSF Certifications for Food and Drinking Water
NSF 372

Description

Valve, Pressure Reducing, Material of Construction Lead Free Bronze, Inlet/Outlet 2 In., NPT X NPT Connection, Max. Working Pressure (PSI) 300, Adjustable Range 25-75 psi, Pressure Setting 50 psi, Max. Temp. (F) 180, Height (In.) 11-1/2, Length (In.) 7-13/100, Certification CA AB1953, VT ACT 193, Standards ASSE 1003/CSA B356, Compliance ARRA

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
