Shop CENTURY

Belt Drive Motor, 1/2 HP, OEM Replacement Brand: Triangle Engineering

  • Mfr # OTEB2054AV1

  • Zoro # G3067005

product price:
$
253.99
/ea
Free Shipping & Returns

Key Features

Frame
56Z
HP
1/2 HP
Motor Application
OEM Replacement
Motor Design
Split-Phase
Motor Enclosure Design
Open Drip Proof
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
OTEB2054AV1
Zoro #
G3067005
UPC #
-
Country of Origin
China

Dimensions

Shaft Dia.
1/2"
Shaft Length
1 1/2 in
Length Less Shaft
7 7/16 in
Body Dia.
6-1/2"
Manufacturers Warranty Length
1 yr
Overall Length
8 15/16 in
Body Diameter
6.5 in
Frame Size
56Z
Shaft Diameter
1/2 in
Wire Rope Length
8 15/16 in
Length
8 15/16 in

Details

Frame
56Z
HP
1/2 HP
Item
Belt Drive Motor
Motor Application
OEM Replacement
Motor Design
Split-Phase
Motor Enclosure Design
Open Drip Proof
Motor Mounting Type
Rigid Base
Motor Shaft Rotation
CWLE
Motor Sub Application
Belt Drive Fan/Blower
Motor Thermal Protection
Automatic
Nameplate RPM
1725 rpm
No. of Speeds
1
Number of Shafts
1
OEM Replacement Brand
Triangle Engineering
Phase
1
RPM Range
1701-1800
Voltage
115V
Motor Bearings
Ball
Replacement For
Triangle Engineering SPL4213 fan motor: PMTR-SPL4213_A, S56C23A97, S56A09A97, S56A03A97, S56A19A97, S56A62A97, S56A33A97, 320P551, 316P760, 5K36JNA769X, 5K36JNA984X, 5KH36JNA984X, S63NXJDC7562, S63NXSMT-7035, YQC56S17D323B, YQE56S17D318E, HG2K012K, HE2H127N, S55NXNFJ-7059, S55NXPKL-7622, 3WH56A1708AP, 4WE56A1709AP, 4WE56AZ1709AP,YQDS56S17D323BP, 26G89525A,3YH56A1708A-P, XQC56S17D318D, YQD56S17D323B, YQD56S17D318E 320P526, S56A72C22, 4WD56A1709AP, 4YD56AZ1709AP, 4VE56A1709AP,XQD56S17D318D, 3VL56A1708A-P, XQE56S17D318D, 056S17D318D, YQD56S17D318D, S55AXNMZ-7208,S63NXJDC-7562,637562
Ins. Class
B
Max. Ambient Temp.
40 Degrees C
Full Load Amps
8A
Capacitor Required
No
Standards
UL Recognized, CSA Certified
Hz
60 Hz
Motor Service Factor
1.00
Application
Replacement Motor for Triangle Engineering Exhaust Fan
Voltage Compatibility
115V AC, 120V AC
Usable @ 208V
Not Usable at 208V
Usable @ 200V
Not Usable at 200V
Motor Mounting Position
Horizontal
Rotation
CWLE
Mounting
Rigid Base
Number of Speeds
1
Compatible Brand
Triangle Engineering
Motor Enclosure Type
Open Drip Proof
Mounting Position
Horizontal
Insulation Class
B
Ambient Temperature - Maximum
40 Degrees C
Sub Application
Fan/Blower
Bearing Type
Ball
Nameplate Service Factor @ 60 Hz
1
Full Load Current @ 60 Hz
8.0 A

Description

Single Phase, Motor Design Split-Phase, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115V AC, Full Load Amps 8.0 A, 56Z Frame, OEM Replacement Brand Triangle Engineering
