Pool Pump Motor, Capacitor-Start/Run, 1 1/2 HP, 48Y Frame, 3,450 Nameplate RPM

  • Mfr # SQ1152

  • Zoro # G2411132

product price:  $447.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Capacitor-Start/Run
Motor Enclosure Design
Open Dripproof
HP
1 1/2
RPM Range
3,001-3,600
Motor Service Factor
1.47
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
SQ1152
Zoro #
G2411132
UPC #
-
Country of Origin
Thailand

Dimensions

Shaft Dia.
5/8 in
Shaft Length
1 in
Body Dia.
5.6 in
Length Less Shaft
13 1/16 in
Height
5 5/8 in
Overall Length
13 15/16 in
Shaft Dia. (In.)
5/8
Shaft Diameter
5/8 in
Frame Size
48Y
Body Diameter
5.6 in

Details

Item
Square Flange Pool Pump Motor
Motor Design
Capacitor-Start/Run
Motor Enclosure Design
Open Dripproof
HP
1 1/2
RPM Range
3,001-3,600
Motor Service Factor
1.47
Nameplate RPM
3,450
Frame
48Y
Motor Shaft Rotation
CCWSE
Phase
Single
Voltage
230V AC
Full Load Amps
10.4 A
Motor Mounting Type
Face
Motor Efficiency Group
Energy Efficient
Shaft
Threaded 1/2-20 UNF-2A RH
Ins. Class
B
Shaft Material
Stainless Steel
Motor Thermal Protection
Auto
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115/230V AC, 120/240V AC, 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/277V AC, 208-230/460V AC, 230V AC, 240V AC, 277/230V AC
Motor Application
Pump
Design
Two Compartment
Max. Ambient Temp.
50 Degrees C
Hz
60 Hz
Motor Sub Application
Pool and Spa Pump
Standards
CSA, UL
Motor Bearings
Ball
Usable @ 200V
Not Usable at 200V
Motor Shaft Design
Threaded
Motor Mounting Position
Horizontal
No. of Speeds
1
Usable @ 208V
Not Usable at 208V
Motor Frame Material
Steel
Weight
31 lb
Duty Cycle
Continuous
Motor Enclosure Type
Open Drip Proof
Frequency
60 Hz
Sub Application
Pool and Spa Pump
Shaft Design
Threaded
Full Load Current @ 60 Hz
10.4 A
Ambient Temperature - Maximum
50 Degrees C
Bearing Type
Ball
Frame Material
Steel
Product Type
Pump Motor
Application
Pump
Number of Speeds
1
Mounting Position
Horizontal
Nameplate Service Factor @ 60 Hz
1.47
Number of Wires
8
Insulation Class
B

Description

Square Flange Pool Pump Motor, Body Dia. 5.6 in, Duty Cycle Continuous, Frame 48Y, Hz 60 Hz, Full Load Amps 10.4, Height 5 5/8 in, HP 1 1/2, Ins. Class B, Length Less Shaft 13 1/16 in, Max. Ambient Temp. 50 Degrees C, Motor Application Pump, Motor Bearings Ball, Motor Design Capacitor-Start/Run, Motor Efficiency Group Energy Efficient, Motor Enclosure Design Open Dripproof, Motor Frame Material Steel

Restrictions

This item has been restricted from sale in the following states: AZ, CA, FL, NY
