Shop CENTURY

Pool Pump Motor, Capacitor-Start/Run, 1/10, 3/4 HP, 56Y Frame, 3,450/1,725 Nameplate RPM

  • Mfr # B2980
  • Zoro # G4482624
product price:
$
498.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Capacitor-Start/Run
Motor Enclosure Design
Open Dripproof
HP
1/10, 3/4
Motor Service Factor
1.67
RPM Range
3,001-3,600
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
B2980
Zoro #
G4482624
UPC #
-
Country of Origin
Mexico

Dimensions

Shaft Dia.
5/8 in
Shaft Length
1 in
Height
11 in
Bolt Circle Dia.
7 1/8 in
Length Less Shaft
12 3/16 in
Overall Length
13 1/8 in
Shaft Dia. (In.)
5/8
Shaft Diameter
5/8 in
Bolt Circle Diameter
7 1/8 in
Frame Size
56Y
Body Diameter
6.5 in
Wire Rope Length
13 1/8 in
Length
13 1/8 in

Details

Item
Square Flange Pool Pump Motor
Motor Design
Capacitor-Start/Run
Motor Enclosure Design
Open Dripproof
HP
1/10, 3/4
Motor Service Factor
1.67
RPM Range
3,001-3,600
Nameplate RPM
3,450/1,725
Frame
56Y
Motor Shaft Rotation
CCWSE
Phase
Single
Voltage
230V AC
Full Load Amps
5.8/0.90 A
Motor Mounting Type
Face
Motor Sub Application
Pool and Spa Pump
Motor Thermal Protection
Auto
Motor Application
Pump
Hz
60 Hz
Voltage Compatibility
115V AC, 200V AC to 230V AC, 115V AC, 208V AC to 230V AC, 115V AC, 230V AC, 120V AC, 240V AC, 200V AC to 230V AC, 440V AC, 200V AC to 230V AC, 460V AC, 208V AC to 220V AC, 440V AC, 208V AC to 230V AC, 277V AC, 208V AC to 230V AC, 460V AC, 230V AC, 240V AC, 277V AC, 230V AC
Shaft Material
303 Stainless Steel
Standards
CSA (LR4642), UL (E44549)
Ins. Class
F
Finish
Black
Max. Ambient Temp.
50 Degrees C
Shaft
Threaded 1/2-20 UNF-2A RH
Motor Bearings
Ball
Motor Efficiency Group
Energy Efficient
Usable @ 208V
Not Usable at 208V
Weight
31 lb
Usable @ 200V
Not Usable at 200V
Duty Cycle
Continuous
Motor Mounting Position
Horizontal
Max. SF Amps
5.8
Motor Shaft Design
Threaded
No. of Speeds
2
Motor Frame Material
Steel
Application
Pump
Motor Enclosure Type
Open Drip Proof
Nameplate Service Factor @ 60 Hz
1.67
Product Type
Pump Motor
Bearing Type
Ball
Frame Material
Steel
Shaft Design
Threaded
Number of Wires
15
Number of Speeds
2
Sub Application
Pool and Spa Pump
Ambient Temperature - Maximum
50 Degrees C
Mounting Position
Horizontal
Full Load Current @ 60 Hz
5.8/0.90 A
Frequency
60 Hz
Insulation Class
F
Service Factor Current
5.8 A

Description

Square Flange Pool Pump Motor, Bolt Circle Dia. 7 1/8 in, Duty Cycle Continuous, Finish Black, Frame 56Y, Hz 60 Hz, Full Load Amps 5.8/0.90, Height 11 in, HP 1/10, 3/4, Ins. Class F, Length Less Shaft 12 3/16 in, Max. Ambient Temp. 50 Degrees C, Max. SF Amps 5.8, Motor Application Pump, Motor Bearings Ball, Motor Design Capacitor-Start/Run, Motor Efficiency Group Energy Efficient, Motor Enclosure Design Open Dripproof, Motor Frame Material Steel

Restrictions

This item has been restricted from sale in the following states: CA, NY
