Pool Pump Motor, Permanent Split Capacitor, 1 HP, 56C Frame, 3,450 Nameplate RPM

  • Mfr # B122

  • Zoro # G3201834

product price:  $343.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Dripproof
HP
1
RPM Range
3,001-3,600
Motor Service Factor
1.4
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
B122
Zoro #
G3201834
UPC #
-
Country of Origin
China

Dimensions

Shaft Dia.
5/8 in
Shaft Length
2 1/8 in
Overall Length
11 7/8 in
Length Less Shaft
9 13/16 in
Body Dia.
6.5 in
Height
11 in
Shaft Dia. (In.)
5/8
Body Diameter
6.5 in
Shaft Diameter
5/8 in
Frame Size
56C
Wire Rope Length
11 7/8 in

Details

Item
Pool and Spa Pump Motor
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Dripproof
HP
1
RPM Range
3,001-3,600
Motor Service Factor
1.4
Nameplate RPM
3,450
Frame
56C
Motor Shaft Rotation
CCWSE
Voltage
115/230V AC
Phase
Single
Full Load Amps
7.2/14.4 A
Motor Mounting Type
Face
Motor Application
Pump
Motor Thermal Protection
Auto
Ambient Temperature
50 Degrees C
Hz
60 Hz
Shaft
Keyed
Motor Flange Material
Aluminum
Motor Efficiency Group
Standard Efficient
Shaft Material
AISI 1215 Steel
Finish
Black
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 230V AC, 240V AC
Motor Bearings
Ball
Ins. Class
B
Motor Sub Application
Pool and Spa Pump
Standards
CSA (LR43341/LR94643), UL (E44549/E25022), UL 1081 Approvable
Max. Ambient Temp.
50 Degrees C
Usable @ 208V
Not Usable at 208V
Weight
26 lb
Max. SF Amps
14.4
Usable @ 200V
Not Usable at 200V
Motor Frame Material
Steel
Motor Shaft Design
Keyed
No. of Speeds
1
Duty Cycle
Continuous
Number of Speeds
1
Bearing Type
Ball
Service Factor Current
14.4 A
Sub Application
Pool and Spa Pump
Motor Enclosure Type
Open Drip Proof
Application
Pump
Product Type
Pump Motor
Insulation Class
B
Number of Wires
8
Nameplate Service Factor @ 60 Hz
1.4
Frequency
60 Hz
Shaft Design
Keyed
Full Load Current @ 60 Hz
7.2/14.4 A
Efficiency Rating
Standard Efficiency (IE1)
Frame Material
Steel
Ambient Temperature - Maximum
50 Degrees C

Description

Pool and Spa Pump Motor, Body Dia. 6.5 in, Duty Cycle Continuous, Finish Black, Frame 56C, Hz 60 Hz, Full Load Amps 7.2/14.4, Height 11 in, HP 1, Ins. Class B, Length Less Shaft 9 13/16 in, Max. Ambient Temp. 50 Degrees C, Max. SF Amps 14.4, Motor Application Pump, Motor Bearings Ball, Motor Design Permanent Split Capacitor, Motor Efficiency Group Standard Efficient, Motor Enclosure Design Open Dripproof, Motor Frame Material Steel

Restrictions

This item has been restricted from sale in the following states: AZ, CA, FL, NY
