Shop CHICAGO PNEUMATIC

Right Angle Die Grinder, 1/4 in NPT Female Air Inlet, 1/4 in Collet, Medium Duty, 17,000 RPM

  • Mfr # CP9107

  • Zoro # G3600195

product price:
$
119.99
/ea
Free Shipping & Returns

Key Features

Overall Length
4 11/16 in
Air Inlet
1/4 in NPT Female
Horsepower
0.2 hp
Free Speed
17,000 RPM
Max. Speed
17,000 RPM
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
CP9107
Zoro #
G3600195
UPC #
015451539061
Country of Origin
Taiwan, Province of China

Dimensions

Overall Length
4 11/16 in
Min. Hose Size
3/8 in
Air Inlet Connection Size
1/4 in
Collet Size
1/4 in
Hose Size - Minimum
3/8 in
Wire Rope Length
4 11/16 in
Length
4 11/16 in

Details

Item
Die Grinder
Air Inlet
1/4 in NPT Female
Horsepower
0.2 hp
Free Speed
17,000 RPM
Max. Speed
17,000 RPM
Grinder Type
Right Angle
Includes
(2) Spanner Wrenches
Bearing Type
Ball
Throttle
Trigger
Collet
1/4 in
Variable Speed
Yes
Duty
Medium Duty
CFM @ Full Load
16.0
Handle Material
Rubber
Grinder Orientation
Straight
Average CFM @ 15 Second Run Time
8.0
Tool Weight
1.5 lb
Features
Operator Comfort and Control
Application
General Maintenance Application
Standards
ISO-28927-12
Air Inlet Type
NPT
Switch Type
Trigger
Tool Style
Right Angle
Air Consumption
16 cfm
Power Source
Air Powered
Minimum Speed
17,000 RPM
Vibration Level
3 m/sq sec
Kit Contents
(1) Bare Tool
Accessory Free Tool Change
No
Exhaust Location
Rear
Switch Location
Bottom
Series
CP91 Series
Air Inlet Gender
Female
Air Pressure
90 psi
Tool Life
Long Lasting
Speed - Minimum
17,000 RPM
Frequency of Use
Frequent Maintenance to Heavy Production
Robot Mounting Components Included
Tool Only
Tool Series
CP91
Speed - Maximum
17,000 RPM
Power Source - TS Only
Air Powered
Power Source - old
Air Powered

Description

Die Grinder, Duty Medium Duty, Horsepower 0.2 hp, Collet Size 1/4 in, Grinder Orientation Straight, Air Inlet Connection Size 1/4 in, Air Inlet Gender Female, Max. Speed 17,000 RPM, Air Inlet Type NPT, Air Inlet 1/4 in NPT Female, Tool Style Right Angle, Kit Contents (1) Bare Tool, Includes (2) Spanner Wrenches, Switch Location Bottom, Power Source Air Powered
