21PC 118 Degree General Purpose Jobber Lngth Drill Set Cle-Line 1899 Steam Oxide HSS RHS/RHC 1/16-3/8x1/64

  • Mfr # C21114
  • Zoro # G0535315
product price:
$
57.65
/ea

Key Features

Number of Pieces
21
Cutting Direction
Right Hand
Drill Bit Point Angle
118 Degrees
Drill Bit Material
High Speed Steel
Includes
Metal Drill Index
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
C21114
Zoro #
G0535315
UPC #
697334211143
Country of Origin
United States

Dimensions

Shank Dia.
1/16 in
Depth:Dia. Ratio
4xD
Drill Bit Dimension Type
Fractional Inch
Sizes Included
1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 5/32", 11/64", 3/16", 13/64", 7/32", 15/64", 1/4", 17/64", 9/32", 19/64", 5/16", 21/64", 11/32", 23/64", 3/8"
Drill Bit Size
1/16 in to 3/8 in by 64ths
Depth x Dia. Ratio
4xD
Drill Length Class
Jobber-Length
Smallest Drill Bit Size
1/16 in
Drill Bit Sizes Included
1/16 in, 1/4 in, 1/8 in, 11/32 in, 11/64 in, 13/64 in, 15/64 in, 17/64 in, 19/64 in, 21/64 in, 23/64 in, 3/16 in, 3/32 in, 3/8 in, 5/16 in, 5/32 in, 5/64 in, 7/32 in, 7/64 in, 9/32 in, 9/64 in
Largest Drill Bit Size
3/8 in
Overall Length
1 7/8 in, 2 in, 2 1/4 in, 2 5/8 in, 2 3/4 in, 2 7/8 in, 3 1/8 in, 3 1/4 in, 3 1/2 in, 3 5/8 in, 3 3/4 in, 3 7/8 in, 4 in
Wire Rope Length
1 7/8 in, 2 in, 2 1/4 in, 2 5/8 in, 2 3/4 in, 2 7/8 in, 3 1/8 in, 3 1/4 in, 3 1/2 in, 3 5/8 in, 3 3/4 in, 3 7/8 in, 4 in
Length
1 7/8 in, 2 in, 2 1/4 in, 2 5/8 in, 2 3/4 in, 2 7/8 in, 3 1/8 in, 3 1/4 in, 3 1/2 in, 3 5/8 in, 3 3/4 in, 3 7/8 in, 4 in

Details

Item
Jobber Length Drill Bit Set
Number of Pieces
21
Cutting Direction
Right Hand
Drill Bit Point Angle
118 Degrees
Drill Bit Material
High Speed Steel
Includes
Metal Drill Index
List Number
1899
Drill Bit Grouping
Drill Bit Set
Point Type
Conventional Point
Standards
ASME B94.11M-1993, DIN 338
Coolant Fed
Non-Coolant Through
Measurement System
Fractional Inch
Drill Bit Point Type
Conventional Point
Primary Material Application
Cast Iron, Steel
Material - Machining
High Speed Steel
Shank Type - Machining
Straight
Number of Drill Bits
21
Finish - Machining
Black Oxide
Material Grade - Machining
General Purpose
Aircraft Drill
No
Drill Bit Case Type
Metal Index
Flute Type
Spiral
Spiral Direction
Right Hand
Primary Material Application ISO Code
K, P
Number of Flutes
2
Helix Angle - Maximum
34 Degrees
Helix Angle - Minimum
21 Degrees

Description

The CLE-LINE C21114 is a jobber length drill bit set consisting of 21 pieces made from high speed steel with general purpose machining grade. 1/16 in to 3/8 in straight shank drill bit sizes from 1/16 in to 3/8 in are manufactured for fractional inch drill bit sizes from 1/16 in to 3/8 in. Each bit features a conventional 118-degree point and a straight shank, with two flutes and a right-hand spiral direction. The set is housed in a metal drill index for storage.

Key Features:

  • 21 drill bits in fractional sizes from 1/16" to 3/8" by 64ths.
  • Jobber length with overall lengths varying approximately from 1 7/8" to 4".
  • Material: High speed steel, general purpose grade.
  • Point type: Conventional 118-degree angle.
  • Shank type: Straight with 1/16 in straight shank diameter.
  • Flutes: 2 with spiral right-hand direction and helix angle between 21 and 34 degrees.
  • Includes metal drill bit index for storage.
  • Meets ASME B94.11M-1993 and DIN 338 standards.
  • Primary applications include drilling in cast iron and steel (ISO codes K, P).
