Water Proof Limit Switch, Plunger, Roller, 1NO, Not Rated AC, Actuator Location: Top

  • Mfr # J4401-517
  • Zoro # G1686517
product price:
$
603.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
1NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
Not Rated
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
J4401-517
Zoro #
G1686517
UPC #
-
Country of Origin
United States

Dimensions

Height
4.00"
Body Depth - Limit Switch
0.87 in
Depth
1.01"
Body Height - Limit Switch
2.85 in
Body Width - Limit Switch
0.87 in
Actuator Length - Limit Switch
0.56 in
Roller Dia.
0.31 in
Width
1.00"
Actuator Length
0.56"
Body Height
2.85 in
Body Depth
0.87 in
Body Width
0.87 in

Details

Item
Water Proof Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
1NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
Not Rated
DC Contact Rating - Limit Switch
5A @ 28V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Stem
Travel
0.56 in Nominal
Voltage Rating
28VDC
Body Material
Stainless steel
Body Style (Limit Switch)
Miniature
Amps
5
Actuator Location (Limit Switch)
Top
Boot Sealed Actuator (Limit Switch)
No
Boot Sealed Actuator - Limit Switch
No
Arm Material
Stainless Steel
Actuator Location
Top
Actuator Style
Plunger
Series
J4
AC Contact Rating
Not Rated
NEMA Rating
No Nema Rating
Stem Thread - Limit Switch
9/16-18 UNF x 0.31 in
Limit Switch Style
Water Proof Limit Switch
Contact Form - Limit Switch
1NO
Mounting Hole Pattern - Limit Switch
No Holes
DC Contact Rating
5 A @ 28 V
Movement
Vertical
Actuator Style (Limit Switch)
Plunger, Roller
Basic Actuator Style (Limit Switch)
Plunger
Electrical Connection
Flying Leads
Contact Form
1NO
Operating Temp. Range
-40 Degrees to 185 Degrees F
IP Rating
IP68
Mounting Hole Spacing - Limit Switch
No Holes
Mounting Hole - Limit Switch
No Holes
Boot Sealed Actuator
No Boot Included
Directional Movement
Linear
NEMA Enclosure Rating
No Enclosure
Number of Mounting Holes
0
Operating Force - Maximum
48 ozf
Action
Momentary
Includes Actuator
Actuator Included
Mounting Style
Stem
Plunger Adjustability
Fixed
Total Travel
0.56 in
Roller Adjustability
Fixed
Operating Temperature - Minimum
-49 Degrees F
Hazardous Location Specification
Not Rated
Operating Temperature - Maximum
302 Degrees F

Description

Limit Switch, Actuator Style - Limit Switch Plunger, Roller, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch Not Rated, DC Contact Rating - Limit Switch 5A @ 28V, Contact Form- Switches 1NO, Actuator Length - Limit Switch 0.56 in, Body Height - Limit Switch 2.85 in, Body Width - Limit Switch 0.87 in, Body Depth - Limit Switch 0.87 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating No NEMA Rating, Mounting - Limit Switch Stem
