Capacitor-Start Belt Drive Motor, 1/3 HP, 115/230V AC Voltage, 56 Frame, 1,725 Nameplate RPM

  • Mfr # 6K366
  • Zoro # G0623524
product price:
$
297.99
/ea
Free Shipping & Returns

Key Features

Motor Enclosure Design
Open Dripproof
Motor Mounting Type
Cradle Base
HP
1/3
RPM Range
1,701-1,800
Voltage
115V AC, 230V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
6K366
Zoro #
G0623524
UPC #
190735365779
Country of Origin
Mexico

Dimensions

Shaft Length
1 7/8 in
Manufacturers Warranty Length
1 yr
Overall Length
10 7/8 in
Shaft Dia.
5/8 in
Shaft Diameter
5/8 in
Frame Size
56

Details

Item
Belt Drive Motor
Motor Enclosure Design
Open Dripproof
Motor Mounting Type
Cradle Base
HP
1/3
RPM Range
1,701-1,800
Voltage
115V AC, 230V AC
Frame
56
Motor Thermal Protection
Auto
Motor Service Factor
1.35
No. of Speeds
1
Voltage Compatibility
115V AC, 200V AC to 230V AC, 115V AC, 208V AC to 230V AC, 115V AC, 230V AC, 115V AC, 120V AC, 240V AC, 230V AC, 240V AC
Motor Application
HVAC/R
Motor Sub Application
Belt Drive Fan/Blower
Nameplate RPM
1,725
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Design
Capacitor-Start
Standards
UL: Multiple List under E37403CSA Certified (156060)
Ins. Class
B
Footnotes
6
Motor Bearings
Ball
Max. Ambient Temp.
104 Degrees F
Full Load Amps
5.7/2.8 A
Phase
Single
Hz
50/60 Hz
Duty
Continuous
Frame Material
Steel
Duty Cycle
Continuous
Number of Speeds
1
Manufacturers Warranty
1 yr
Frequency
60/50 Hz
Application
Fan/Blower
Nameplate Service Factor @ 60 Hz
1.35
Full Load Current @ 60 Hz
5.7/2.8 A
Mounting Position
All Angle
Shaft Design
Keyed
Product Type
Fan and Blower Motor
Ambient Temperature - Maximum
40 Degrees C
Insulation Class
B
Bearing Type
Ball
Drive Type
Belt Drive
Motor Enclosure Type
Open Drip Proof

Description

Fan and Blower Motor, Single Phase, Motor Design Capacitor-Start, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, 5.7/2.8 A Full Load Amps, 56 Frame, 60/50 Hz Hz, Motor Service Factor 1.35, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base, Motor Frame Material Steel, Motor Mounting Position All Angle
