Shop DAYTON

HVAC Motor, 1/15 HP, 1550 rpm, 115V, 3.3

  • Mfr # 71638779M

  • Zoro # G1754566

product price:
$
79.15
/ea

Key Features

Voltage
115V AC
Nameplate RPM
1,550
Motor Enclosure Design
Open Air-Over
Number of Speeds
1
HP
1/15
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
71638779M
Zoro #
G1754566
UPC #
00799471519479
Country of Origin
Mexico
Voltage
115V AC
Nameplate RPM
1,550
Motor Enclosure Design
Open Air-Over
Number of Speeds
1
HP
1/15
RPM Range
1,501-1,600
Motor Thermal Protection
Auto
Application
OEM and Replacement Use In A Wide Variety of Fan and Blower
Standards
CSA Certified, UL Recognized
Number of Shafts
1
Motor Shaft Design
Flat
Frame
3.3
Ins. Class
B
Duty
Continuous
Stud/Base Mtg. Pattern
6-1/8 in
Voltage Compatibility
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Item
HVAC Motor
Hz
60/50 Hz
Footnotes
6
Motor Service Factor
1
Max. Ambient Temp.
40 Degrees C
Full Load Amps
2.5 A
Motor Shaft Rotation
CCWSE
Motor Sub Application
Direct Drive Fan/Blower
Motor Application
HVAC/R
Motor Mounting Type
Lug
No. of Speeds
1
Motor Design
Shaded Pole
Motor Bearings
Sleeve
Phase
Single
Capacitor Required
Capacitor Not Required
Usable @ 200V
Not Usable at 200V
RPM @ 50Hz
1,550 RPM
Usable @ 208V
Not Usable at 208V
Full Load Amps @ 50Hz
2.5 A
Motor Mounting Position
All Angle
HP @ 50Hz
1/15
Voltage @ 50Hz
115V AC
Duty Cycle
Continuous
Service Factor @ 50Hz
1
Mounting
Lug
Type
OEM Replacement
Shaft Design
Flat
Full Load Current @ 50 Hz
2.5 A
Sub Application
General Purpose
Nameplate Voltage @ 50 Hz
115V AC
Nameplate Service Factor @ 50 Hz
1
Frequency
60/50 Hz
Motor Enclosure Type
Open Air Over
Ambient Temperature - Maximum
40 Degrees C
Bearing Type
Sleeve
Nameplate RPM @ 50 Hz
1,550 RPM
Full Load Current @ 60 Hz
2.5 A
Frame Material
Steel
Insulation Class
B
Wattage
49 W
Drive Type
Direct Drive
Nameplate Service Factor @ 60 Hz
1
Nameplate Horsepower @ 50 Hz
1/15 hp

Description

HVAC Motor, Single Phase, Motor Design Shaded Pole, 1/15 hp HP, Nameplate RPM 1,550 RPM, No. of Speeds 1, Voltage 115V AC, 2.5 A Full Load Amps, 3.3 Frame, Output Watts 49 W, 60/50 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CCWSE, Motor Enclosure Design Open Air Over, Motor Mounting Type Lug, Motor Frame Material Steel
