Shop DAYTON

Limit Switch, Plunger, Roller Lever, SPDT, 15A at 480V AC, Actuator Location: Top

  • Mfr # 12T930

  • Zoro # G4090371

product price:
$
59.99
/ea

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller Lever
Contact Form- Switches
SPDT
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
15A at 480V
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
12T930
Zoro #
G4090371
UPC #
190735116630
Country of Origin
China

Dimensions

Body Height - Limit Switch
1.76 in
Body Depth - Limit Switch
1.01 in
Height
4.68"
Depth
2.13"
Body Width - Limit Switch
3.39 in
Width
3.39"
Mounting Hole Diameter
0.17 in
Body Height
1.76 in
Body Depth
1.01 in
Body Width
3.39 in

Details

Item
Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller Lever
Contact Form- Switches
SPDT
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
15A at 480V
DC Contact Rating - Limit Switch
15A at 480V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Bottom Flange
Mounting Hole - Limit Switch
(2) 0.17 in dia
DC Contact Rating
15 A @ 480 V
Actuator Style
Roller Lever Plunger
Movement
Horizontal
NEMA Rating
13, 3, 4
Basic Actuator Style (Limit Switch)
Plunger
Contact Form - Limit Switch
SPDT
Mounting Hole Spacing - Limit Switch
2.13 in
Number of Poles
1
Body Style (Limit Switch)
Miniature
IP Rating
IP65
Voltage Rating
480VAC/DC
Boot Sealed Actuator - Limit Switch
Yes
Wiring Entry
1/2 in NPT
Travel
Maximum Pre-Travel 5 mm, Over Travel 4 mm
Amps
15
Limit Switch Style
General Purpose Limit Switch
Operating Force
22.66 in-oz
Series
Dayton
Actuator Location
Top
Actuator Style (Limit Switch)
Plunger, Roller Lever
Stem Thread - Limit Switch
No Stem
Operating Temp. Range
-14 Degrees to 176 Degrees F
Actuator Location (Limit Switch)
Top
Standards
CE, CSA, UL Listed
Mounting Hole Pattern - Limit Switch
2 Hole Horizontal
Contact Form
SPDT
Boot Sealed Actuator (Limit Switch)
Yes
AC Contact Rating
15 A @ 480 V
Electrical Connection
Screw Terminals
Directional Movement
Linear
Action
A
Operating Temperature - Minimum
-14 Degrees F
Mounting Hole Horizontal Center to Center Distance
54 mm
Boot Sealed Actuator
Boot Included
Pretravel
0.197 in
Operating Temperature - Maximum
176 Degrees F
Mounting Style
Bottom Flange
Overtravel
0.16 in
Operating Torque - Maximum
1.42 in-lb
NEMA Enclosure Rating
13, 3, 4
Number of Mounting Holes
2

Description

Limit Switch, Actuator Style - Limit Switch Plunger, Roller Lever, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 15A @ 480V, DC Contact Rating - Limit Switch 15A @ 480V, Contact Form- Switches SPDT, Body Height - Limit Switch 1.76 in, Body Width - Limit Switch 3.39 in, Body Depth - Limit Switch 1.01 in, Boot Sealed Actuator - Limit Switch Yes, Body Style - Limit Switch Miniature, NEMA Rating 13, 3, 4, Mounting - Limit Switch Bottom Flange
