Hum/TempSnsr, 4.5", 2.8", 4 to 20 mA, CE
- Mfr # RHP-3N4B
- Zoro # G207158396
product price:Â
$
165.99
/ea
Free Shipping & Returns
Key Features
Height
1.5 in; 38.1 mm
Length
5.1 in
Width
4.1 in; 104.13999999999999 mm
Weight
0.25 lbs
Input Voltage
10 to 35V DC
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- RHP-3N4B
- Zoro #
- G207158396
- UPC #
- -
- Country of Origin
- United States
- Weight
- 0.25 lbs
- Input Voltage
- 10 to 35V DC
- Temperature Sensor
- 10K Ohm Type II Thermistor
- Humidity Accuracy
- +/-3%
- Hysteresis
- +/-0.8%
- IP Rating
- IP20
- Mounting Style
- Wall Mount
- Response Time
- 8 sec
- Output Power
- 4 to 20 mA
- Standards
- CE
- Humidity Measurement - Maximum
- 100 %
- Process Media Temperature Measurement - Minimum
- -40 Degrees F
- Electrical Connection
- Screw Terminals
- Compensated Temperature - Minimum
- -4 Degrees F
- Operating Temperature - Minimum
- -40 Degrees F
- Temperature Accuracy
- +/-0.36 Degrees F @ 77 Degrees F
- Operating Temperature - Maximum
- 140 Degrees F
- Item
- Humidity/Temperature Sensor
- Compensated Temperature - Maximum
- 140 Degrees F
- Enclosure Material
- Polycarbonate
- Relative Humidity Sensor
- Capacitive
- Series
- RHP-E/N
- Humidity Measurement - Minimum
- 0 %
- Process Media Temperature Measurement - Maximum
- 140 Degrees F
Description
Humidity/Temperature Sensor, Maximum Sensed Temperature 140 Degrees F, Minimum Sensed Temperature -40 Degrees F, Temperature Accuracy +/-0.36 Degrees F @ 77 Degrees F, Power Required 10 to 35V DC, Electrical Connections Screw Terminals, Overall Length 2.8 in, IP Rating IP20, Series RHP-E/N, Output 4 to 20 mA, Relative Humidity Range 0 to 100 Percent, Humidity Accuracy +/-3 Percent, Sensing Element Type 10K Ohm Type II Thermistor, Compensated Temperature Range -4 Degrees to 140 Degrees F
