Circuit Breaker, BD Series, 20A, 1 Pole, 120V AC, 10kA
Mfr # BD2020
Zoro # G307449981
product price:Â
$
25.79
/ea
Key Features
Series
BD
Number of Poles
1
AC Voltage Rating
120V AC
Circuit Breaker Mounting Style
Plug In
Max. AIR Rating
10kA
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- BD2020
- Zoro #
- G307449981
- UPC #
- 786676369251
- Country of Origin
- United States
Dimensions
- Frame Size
- BR
- Width
- 1.60 in
- Depth
- 3 in
- Height
- 1 in
- Max. Wire Size
- 4 AWG (Cu/Al)
- Min. Wire Size
- 14 AWG (Cu/Al)
- Wire Size
- #14-4 AWG Cu/Al
Details
- Item
- Circuit Breaker
- Series
- BD
- Amps
- 20 A
- Number of Poles
- 1
- AC Voltage Rating
- 120V AC
- Circuit Breaker Type
- Duplex
- Circuit Breaker Mounting Style
- Plug In
- Max. AIR Rating
- 10kA
- Trip Type
- Thermal Magnetic
- DC Voltage Rating
- Not Rated
- Interrupt Rating
- 10 kA
- Features
- Rejection Tab Feature
- Standards
- UL 489
- For Use With
- Type BR Loadcenters
- Special Features
- Includes rejection tab feature
- Compliances
- Federal Specifications Classification W-C375
Description
Switching duty rating, duplex type breaker requires 1 in per breaker Thermal magnetic 40 deg C breakers have rejection tab feature, allows only 42 circuits in the panel in compliance with NEC article 38415 Interchangeable will replace Bryant, Challenger and Westinghouse Type BR 120240 V 10,000 AIR 1 in per breaker
