Shop EM&S

Unit Bearing Motor, 1/47 hp

  • Mfr # ESP-L16EM1
  • Zoro # G3137793
product price:
$
81.89
/ea

Key Features

Motor Sub Application
Refrigerator/Freezer
Output Watts
16 W
HP
1/47
RPM Range
1,401-1,500
Voltage Compatibility
115V AC, 208V AC to 230V AC, 115V AC, 230V AC, 115V AC, 120V AC, 240V AC, 120V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ESP-L16EM1
Zoro #
G3137793
UPC #
-
Country of Origin
United States

Dimensions

Shaft Length
1/2 in
Body Dia.
3 7/8 in
Overall Length
4 in
Cord Length
22 in
Length Less Shaft
3 1/2 in
Shaft Dia.
1/4 in
Body Diameter
3.9 in
Frame Size
Non-Standard
Shaft Diameter
1/4 in
Wire Rope Length
4 in
Length
4 in

Details

Motor Sub Application
Refrigerator/Freezer
Output Watts
16 W
HP
1/47
RPM Range
1,401-1,500
Voltage Compatibility
115V AC, 208V AC to 230V AC, 115V AC, 230V AC, 115V AC, 120V AC, 240V AC, 120V AC
Phase
Single
Voltage
115V AC
Motor Shaft Rotation
CWLE
Nameplate RPM
1,500
Frame
Non-Standard
Motor Design
Shaded Pole
Motor Thermal Protection
Auto
Hz
60 Hz
Motor Application
HVAC/R
Frame Material
Cast Iron
Motor Mounting Type
Rear/Foot
Standards
Meets UL and Canadian Standards for Safety
Motor Bearings
Sleeve
Full Load Amps
0.80 A
Motor Service Factor
1
Ins. Class
A
Motor Enclosure Design
Totally Enclosed Air-Over
Plug Type
Round 2 Pin
Max. Ambient Temp.
40 Degrees C
Item
Unit Bearing Motor
Motor Frame Material
Cast Iron
Motor Mounting Position
All Angle
Motor Shaft Design
Threaded
No. of Speeds
1
Features
Cool running, Quiet Operation, Thick Film Lubricating System for Long Life and Dependability
Usable @ 200V
Not Usable at 200V
Usable @ 208V
Not Usable at 208V
Mounting Holes
Tapped 8-36
Product Type
Unit Bearing Motor
Sub Application
Unit Bearing
Frequency
60 Hz
Wattage
16 W
Number of Speeds
1
Shaft Design
Threaded
Bearing Type
Sleeve
Drive Type
Direct Drive
Full Load Current @ 60 Hz
0.80 A
Application
Condenser Fan
Motor Enclosure Type
Totally Enclosed Air-Over
Insulation Class
A
Mounting Position
Horizontal
Ambient Temperature - Maximum
40 Degrees C

Description

Unit Bearing Motor, Single Phase, Motor Design Shaded Pole, 1/47 HP, Nameplate RPM 1,500, No. of Speeds 1, Voltage 115V AC, 0.80 A Full Load Amps, Non-Standard Frame, Output Watts 16 W, 60 Hz Hz, Usable @ 208V No, Usable @ 200V No, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class A, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CWLE, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Rear/Foot, Motor Frame Material Cast Iron
