Shop EXTECH

Thermometer, LCD, 2.8 in, Thermocouple

  • Mfr # EA15-NIST

  • Zoro # G8333245

product price:
$
545.00
/ea
Free Shipping & Returns
Zoro's best price: not eligible for any other offers or promotions

Key Features

Thermometer Item
Thermocouple Thermometer
Thermometer Thermocouple Type
Type E, Type J, Type K, Type N, Type R, Type S, Type T
Number of Inputs
2
Probe Connector
Mini-Type
Temp. Range (F)
Type E -200 Degrees to 1598 Degrees , Type J -200 Degrees to 1994 Degrees , Type K -200 Degrees to 1999 Degrees , Type N -200 Degrees to 1999 Degrees , Type R 32 Degrees to 1999 Degrees , Type S 32 Degrees to 1999 Degrees , Type T -200 Degrees to 752 Degrees
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
EA15-NIST
Zoro #
G8333245
UPC #
793950411513
Country of Origin
Taiwan, Province of China

Dimensions

Manufacturers Warranty Length
1 yr
Manufacturer Warranty Length
1 yr
Display Size
1.5 in H x 2.8 in W
Display Height
1.5 in
Digit Height
1 in
Display Width
2.8 in
Battery Size
AAA

Details

Thermometer Item
Thermocouple Thermometer
Thermometer Thermocouple Type
Type E, Type J, Type K, Type N, Type R, Type S, Type T
Number of Inputs
2
Probe Connector
Mini-Type
Temp. Range (F)
Type E -200 Degrees to 1598 Degrees , Type J -200 Degrees to 1994 Degrees , Type K -200 Degrees to 1999 Degrees , Type N -200 Degrees to 1999 Degrees , Type R 32 Degrees to 1999 Degrees , Type S 32 Degrees to 1999 Degrees , Type T -200 Degrees to 752 Degrees
Temp. Range (C)
Type E -150 Degrees to 870 Degrees , Type J -150 Degrees to 1090 Degrees , Type K -150 Degrees to 1372 Degrees , Type N -150 Degrees to 1300 Degrees , Type R 2 Degrees to 1767 Degrees , Type S 2 Degrees to 1767 Degrees , Type T -150 Degrees to 400 Degrees
Accuracy
+/-0.05 % + 1.5 Degrees F/0.75 Degrees C (Type J, K, E, T, N), +/-0.05 % + 4 Degrees F/2 Degrees C (Type R, S)
Display
Backlit 2 Line LCD
Battery Type
(6) AAA
Features
Timer Function Displays Elapsed Time Plus The Time When Min/Max Readings Occurred, Offset Key Used for Zero Function to Make Relative Measurements
Data Logging
Yes
Interface
RS232
Calibration Certificate Included
Yes, NIST
Data Hold
Yes
Standards
CE
NIST Certification By
FLIR
Calibration Certificate
NIST
Sampling Rate
3 to 355 sec
Resolution
0.1 Degrees
Auto Power Off
Yes
Item
Thermocouple Thermometer
Includes
(2) Type K Bead Wire Temperature Probe, Batteries, Built-In Stand, Protective Holster
Memory
Min/Max/Avg/Dif
Thermocouple Temperature Range F
-200 Degrees to 1,598 Degrees F (Type E), -200 Degrees to 1,994 Degrees F (Type J), -200 Degrees to 1,999.9 Degrees F (Type K, N), -200 Degrees to 752 Degrees F (Type T), 35 Degrees to 1,999.9 Degrees F (Type R, S)
Temperature Meter Type
Multichannel Thermocouple Temperature Meter with Data Output and Min/Max
For Thermocouple Type
Type E, Type J, Type K, Type N, Type R, Type S, Type T
Sensor Type
Thermocouple
Number of Channels
2
Number of Digits
5
Functions
Degrees F/ Degrees C Switchable, Open Input Indication, Over Range Indication
Power Source Details
(6) AAA Batteries
Included Probes
(2) Type K Bead Wire Temperature Probe
Thermocouple Temperature Range C
-150 Degrees to 1,090 Degrees C (Type J), -150 Degrees to 1,300 Degrees C (Type N), -150 Degrees to 1,370 Degrees C (Type K), -150 Degrees to 400 Degrees C (Type T), -150 Degrees to 870 Degrees C (Type E), 2 Degrees to 1,767 Degrees C (Type R, S)
Includes Batteries
Yes
Temperature Range
-200 Degrees to 1,598 Degrees F/-150 Degrees to 870 Degrees C (Type E), -200 Degrees to 1,994 Degrees F/-150 Degrees to 1,090 Degrees C (Type J), -200 Degrees to 1,999.9 Degrees F/-150 Degrees to 1,300 Degrees C (Type N), -200 Degrees to 1,999.9 Degrees F/-150 Degrees to 1,370 Degrees C (Type K), -200 Degrees to 752 Degrees F/-150 Degrees to 400 Degrees C (Type T), 35 Degrees to 1,999.9 Degrees F/2 Degrees to 1,767 Degrees C (Type R, S)
Includes Wireless Transmission
No
Backlit
Yes
Response Time
1 sec
Digital Display
1.5 in H x 2.8 in W Display with - 5-Digit Backlit LCD - 1 in Digit Height
Display Type
LCD
Data Output Type
RS-232, SD Card
Includes NIST-Traceable Certificate
Yes
Testing Functions
Average Temperature, Differential Temperature, Min/Max Temperature
RTD Temperature Fahrenheit - Minimum
-200 Degrees F
Number of Probes
2
Number of Batteries Required
6
Calibration Certificate Type
NIST Traceable
RTD Temperature Fahrenheit - Maximum
1,999 Degrees F
Thermocouple Temperature Fahrenheit - Minimum
-200 Degrees F (Type E), -200 Degrees F (Type J), -200 Degrees F (Type K, N), -200 Degrees F (Type T), 35 Degrees F (Type R, S)
Meter Type
Handheld
Sensor Technology
Thermocouple
Thermocouple Temperature Fahrenheit - Maximum
1,598 Degrees F (Type E), 1,994 Degrees F (Type J), 1,999.9 Degrees F (Type K, N), 1,999.9 Degrees F (Type R, S), 752 Degrees F (Type T)
Relative Humidity - Maximum
80%
Temperature Units
Celsius, Fahrenheit
Temperature Resolution F
0.1 Degrees F
Relative Humidity - Minimum
0%

Description

Thermocouple Thermometer, Thermocouple, Number of Channels 2, Includes NIST-Traceable Certificate Yes, Accuracy +/-0.05 Percent + 1.5 Degrees F/0.75 Degrees C (Type J, K, E, T, N), +/-0.05 Percent + 4 Degrees F/2 Degrees C (Type R, S)
