Carbide Turning Insert, Parallelogram, ZCMX080304, for Steel
Mfr # 268425 HBZ035
Zoro # G714822513
product price: $18.29
/eaSold in multiples of 10 for $182.90
Key Features
Min. Cutting Depth (ap min)
0.25 mm
Max. Cutting Depth (ap max)
2.75 mm
Insert Thickness
2 mm
Insert Size
80304
Cutting Depth
0.4 mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
268425 HBZ035
Zoro #
G714822513
UPC #
-
Country of Origin
Austria
Dimensions
Min. Cutting Depth (ap min)
0.25 mm
Max. Cutting Depth (ap max)
2.75 mm
Insert Thickness
2 mm
Insert Size
80304
Cutting Depth
0.4 mm
Suitable Tool Diameter
16 mm
Corner Radius
0.4 mm
Details
Workpiece Material
Steel
Item
Indexable Insert for Turning
ISO Number
ZCMX 080304
Inscribed Circle
8 mm
No. of Edges
2
Cutting Conditions
Slightly Interrupted
Insert Material
Carbide
Insert Style
ZCMX
Grade
HBZ035
Coating
PVD
Insert Shape
Parallelogram
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. suitable for tool dia. Dc: 16 mm Grade: HBZ035 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 50 190 m/min
