Carbide Turning Insert, Parallelogram, ZCMX080308, for Steel
Mfr # 268427 HBZ030
Zoro # G514821860
product price: $18.29
/eaSold in multiples of 10 for $182.90
Key Features
No. of Edges
2
Suitable Tool Diameter
16 mm
Coating
CVD
Corner Radius
0.8 mm
Max. Cutting Depth (ap max)
2.75 mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
268427 HBZ030
Zoro #
G514821860
UPC #
-
Country of Origin
Austria
Dimensions
Suitable Tool Diameter
16 mm
Corner Radius
0.8 mm
Max. Cutting Depth (ap max)
2.75 mm
Min. Cutting Depth (ap min)
0.55 mm
Insert Thickness
2 mm
Insert Size
80308
Cutting Depth
0.4 mm
Details
No. of Edges
2
Item
Indexable Insert for Turning
Coating
CVD
Insert Shape
Parallelogram
Grade
HBZ030
ISO Number
ZCMX 080308
Inscribed Circle
8 mm
Insert Material
Carbide
Insert Style
ZCMX
Workpiece Material
Steel
Cutting Conditions
Continuous
Description
Harder substrate for longer tool life with thinner CVD coating. Especially for facing and longitudinal turning applications. suitable for tool dia. Dc: 16 mm Grade: HBZ030 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 70 200 m/min
