Gast
Compressor/Vacuum Pump, 1/3 HP, 50/60 Hz,
- Zoro #: G1707772
- Mfr #: DOA-P707-FB
Tap to zoom
Hover or click to zoom
This item ships free.
(Sign in or create an account for free shipping on orders over $50)
Total: $564.88
Gast #DOA-P707-FB Specifications
- Zoro #: G1707772
- Mfr #: DOA-P707-FB
- Item: Compressor/Vacuum Pump
- Compressor Type: Diaphragm
- HP: 1/3 hp
- Voltage: 110/115V AC
- Full Load Amps: 4.8/3.3
- Max. Vacuum: 25.5 in Hg
- Max. PSI Cont./Int.: 60/60
- Inlet Size: 1/4 in NPT
- Outlet Size: 1/4 in NPT
- Free Air CFM @ 0 PSI: 1.9
- Hz: 50/60
- Free Air CFM @ 20 Vacuum: 0.3
- Free Air CFM @ 0 Vacuum: 1.9
- Overall Height: 7 5/8 in
- Overall Length: 7 5/8 in
- Overall Width: 5 1/8 in
- Free Air CFM @ 30 PSI: 0.9
- Pump Type: Diaphragm
- Inlet Connection Type: NPT
- Maximum Vacuum: 25.5 in Hg
- Inlet Size and Type: 1/4 in NPT
- Maximum Flow Rate @ Pressure: 0.9 cfm @ 30 psi, 1.9 cfm @ 0 psi
- Max. Pressure Cont/Int: 60 psi / 60 psi
- Outlet Size and Type: 1/4 in NPT
- Outlet Connection Type: NPT
- Flow Rate @ 0 psi: 1.9 cfm
- Maximum Continuous Pressure: 60 psi
- Output Power: 1/3 hp
- Frequency: 50 Hz, 60 Hz
- Maximum Intermittent Pressure: 60 psi
- Maximum Flow Rate: 0.9 cfm @ 30 psi, 1.9 cfm @ 0 psi
- Current Rating: 3.3 A, 4.8 A
- Flow Rate @ 30 psi: 0.9 cfm
- Inlet Connection Type: NPT
- Outlet Connection Type: NPT
- Country of Origin (subject to change): United States
Description
Compressor/Vacuum Pump, Compressor Type Diaphragm, 1/3 hp HP, Voltage 110/115V AC, 50/60 Hz, 4.8/3.3 Full Load Amps, Inlet Size 1/4 in NPT, Outlet Size 1/4 in NPT, Max. Vacuum 25.5 in Hg, Max. PSI Cont./Int. 60/60, Free Air CFM @ 0 PSI 1.9, Free Air CFM @ 30 PSI 0.9, Free Air CFM @ 0 Vacuum 1.9, Free Air CFM @ 20 Vacuum 0.3, Overall Length 7 5/8 in, Overall Width 5 1/8 in, Overall Height 7 5/8 in
