Double Diaphragm Pump, 1/2", 90 gpm, 0.4gal

Mfr # SP4F.0024
Zoro # G923361278

24,968.99

Additional $200.00 delivery surcharge applies per item.

Key Features

Includes Solenoid

No Solenoid Included

Air Intake Pressure (Maximum)

120 psi

Media Temperature (Maximum)

250 Degrees F

Overall Length

16 in

Air Intake Connection Type

NPT

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: SP4F.0024
Zoro #: G923361278
UPC #: 755652880066
Country of Origin: United States

Dimensions

Overall Length: 16 in
Media Intake Connection Size: 4 in
Media Discharge Connection Size: 4 in
Overall Height: 19.9 in
Air Intake Connection Size: 1/2 in
Manufacturers Warranty Length: 1 yr
Solid Diameter (Maximum): 3.8 in
Overall Width: 23.1 in
Wire Rope Length: 16 in
Length: 16 in

Details

Includes Solenoid: No Solenoid Included
Air Intake Pressure (Maximum): 120 psi
Media Temperature (Maximum): 250 Degrees F
Air Intake Connection Type: NPT
Item: Double Diaphragm Pump
For Use With Potable Systems: Yes
Manifold Port Connection Type: Single Port
Displacement Per Stroke: 0.4 gal
Check Seat Material: Stainless Steel
Includes: Manuals
Fluid Chamber Assembly Type: Bolted
Viscosity (Maximum): 15,000 cps
Mounting Hardware Material: Stainless Steel
Wetted Body Material: Stainless Steel
Manifold Connection Standard: Tri-Clamp
Center Section Material: Stainless Steel
Diaphragm Reinforcement: Overmolded
Media Discharge Location: Top
Media Intake Location: Bottom
Valve Material: Stainless Steel
Includes Clean In Place Technology: Clean In Place Included
Media Discharge Port Configuration: Center Vertical
Standards: EC 1935/2004, FDA Compliant, USP Class VI
Media Intake Connection Type: Tri-Clamp
Diaphragm Base Material: PTFE
Material Conductivity: Conductive
Media Temperature (Minimum): -40 Degrees F
Operating Pressure (Maximum): 120 psi
Air Consumption (Maximum): 235 scfm
Pump Operation Type: Air
Series: SaniForce
Media Discharge Connection Type: Tri-Clamp
Flow Rate (Maximum): 90 gpm
Media Intake Port Configuration: Center Vertical
Chemical Compatibility: Acetone,Alcohol,Alkaline,Ammonium Hydroxide,Antifreeze,Benzoic Acid,Boric Acid 10%,Calcium Carbonate,Citric Acid,D-Limonene,Detergents,Diesel,Diesel Exhaust Fluid,Diethylene Glycol,Gasoline,Glycerol,Hydraulic Fluid,Hydrocarbons,Ink,Kerosene,Ketones,Lactic Acid,Motor Oil,Oil,Oil-Based Paint,Phosphoric Acid 40%,Phosphoric Acid 50%,Potassium Hydroxide,Propylene Glycol,Soap,Sodium Hydroxide,Sodium Hydroxide 10%,Sodium Hydroxide 20%,Transmission Fluid,Water
Food Compatibility: Agave Syrup, Beer, Beet Sugar Liquids, Butter, Buttermilk, Cane Juice, Caramel, Carbonated Water, Cheese, Chocolate, Chocolate Syrup, Cider, Coconut Oil, Coffee, Condiments, Cooking Oil, Corn Oil, Corn Syrup, Cottonseed Oil, Cream (Candy), Cream (Dairy), Distilled Spirits, Edible Oil, Egg, Fresh Water, Fruit, Fruit Juice, Fruit Juice Concentrate, Gelatin, Glucose, Grape Juice, High Fructose Corn Syrup, Honey, Ice Cream, Icing, Jam, Jelly, Ketchup, Liquid Sugar, Mayonnaise, Milk, Molasses, Mustard, Olive Oil, Palm Oil, Peanut Butter, Peanut Oil, Rapeseed Oil, Rum, Salad Dressing, Sesame Seed Oil, Soy Sauce, Soybean Oil, Starch, Tomato Juice, Tomato Paste, Vegetable Juice, Vegetable Oil, Vinegar, Whey, Whiskey & Wines, Wine, Yogurt
Feet of Head (Maximum): 277 ft
Pump Assembly Type: Bolt
Diaphragm Backing Material: EPDM
Surface Roughness: 32 ra

Description

Double Diaphragm Pump, Air Consumption (Maximum) 235 scfm, Air Intake Connection Size 1/2 in, Air Intake Connection Type NPT, Check Seat Material Stainless Steel, Feet of Head (Maximum) 277 ft, Flow Rate (Maximum) 90 gpm, Media Discharge Connection Size 4 in, Media Discharge Connection Type Tri-Clamp, Media Discharge Location Top, Media Intake Connection Size 4 in, Media Intake Connection Type Tri-Clamp, Media Intake Location Bottom, Media Temperature (Maximum) 250 Degrees F
