Motor, 1/3 hp, OEM Replacement Brand: 874L38 Replacement For: B180-62

  • Mfr # B180-62

  • Zoro # G915830058

product price:
$
84.99
/ea

Key Features

Frame
39
HP
1/3 hp
Motor Design
Capacitor-Start
Motor Enclosure Design
Open Air-Over
Motor Shaft Rotation
CW/CCW
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
B180-62
Zoro #
G915830058
UPC #
-
Country of Origin
China
Frame
39
HP
1/3 hp
Item
Evaporative Cooler Motor
Motor Design
Capacitor-Start
Motor Enclosure Design
Open Air-Over
Motor Shaft Rotation
CW/CCW
Nameplate RPM
1,550
Number of Shafts
1
OEM Replacement Brand
874L38
Voltage
115V AC
Motor Bearings
Ball
Replacement For
B180-62
Ins. Class
A
Max. Ambient Temp.
40 Degrees C
Full Load Amps
3.8/2.9 A
Capacitor Required
Capacitor Included
Standards
UL Recognized US and Canada
Motor Shaft Design
Threaded
Motor Service Factor
1
Application
Evaporative Cooler
Motor Frame Material
Steel
Usable @ 208V
Not Usable at 208V
Compatible Manufacturer Model Number
W6100
Motor Mounting Position
Horizontal
Duty Cycle
Continuous
Weight
20 lb
Usable @ 200V
Not Usable at 200V
Extended Thru-Bolts
No
Conduit Box Location
Interior
Compatible Brand
Hessaire
Nominal Efficiency
0.65 %
Bearing Type
Ball
Insulation Class
A
Nameplate Service Factor @ 60 Hz
1
Manufacturers Warranty
1 yr
Motor Enclosure Type
Open Air Over
Sub Application
Evaporative Cooler
Frame Material
Steel
Mounting Position
Horizontal
Compatible Manufacturer Part Number
W6100
Product Type
Evaporative Cooler Motor
Duty
Continuous
Ambient Temperature - Maximum
40 Degrees C
Shaft Design
Threaded
Full Load Current @ 60 Hz
3.8/2.9 A

Description

Evaporative Cooler Motor, Not Applicable Phase, Motor Design Capacitor-Start, 1/3 hp HP, Nameplate RPM 1,550 RPM, No. of Speeds Not Applicable, Voltage 115V AC, Full Load Amps 3.8/2.9 A, 39 Frame, OEM Replacement Brand 874L38, Replacement For B180-62, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Not Applicable, Ins. Class A, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW
