Air Pressure Switch - DL 16KTG 3, -1.5 to 150 mbar, Adjustable

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 16KTG 3 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It supports positive, negative, and differential pressure measurements in systems using air, flue gas, or non-aggressive gases. The device features a switching point adjustment via a setting dial that allows adjustment within the specified switching point range.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Tube connections: Rp 1/4, Rp 1/8 (CE versions); 1/4" NPT, 1/8" NPT (UL versions)
• Contact options: Silver or gold contacts with varying voltage and current ratings depending on version
• Electrical connection: Screw terminals with M16x1.5 cable gland or 1/2" NPT conduit; includes a four-pin plug and socket
• Certified by EU, UL listed, FM approved, AGA approved; RoHS compliant
• Silicon-free construction
