Shop HONEYWELL

Limit Switch, Plunger, Roller, 2NC/2NO, 10A at 300V AC, Actuator Location: Top

  • Mfr # GLEA24C

  • Zoro # G4175893

product price:
$
215.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 300V
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
GLEA24C
Zoro #
G4175893
UPC #
-
Country of Origin
Mexico
Item
Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 300V
DC Contact Rating - Limit Switch
10A at 250V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Surface
Amps
10
Actuator Location (Limit Switch)
Top
Contact Form
2NO/2NC
Mounting Hole - Limit Switch
(4) 0.12 in dia
Series
GLE
Mounting Hole Spacing - Limit Switch
0,87 in, 1.65 in
NEMA Rating
1, 12, 13, 4
Travel
Differential Travel 0.024 in, Maximum Pretravel 0.12 in, Minimum Over Travel 0.118 in
Body Style (Limit Switch)
Miniature
Movement
Linear
AC Contact Rating
10 A @ 300 V
Boot Sealed Actuator - Limit Switch
No
Operating Temp. Range
-40 Degrees to 185 Degrees F
Mounting Hole Pattern - Limit Switch
4 Hole Inline
Arm Material
Metal
Electrical Connection
Screw Terminals
Basic Actuator Style (Limit Switch)
Plunger
Standards
CCC, CE, CSA, UL Listed
Actuator Style
Roller Plunger
Contact Form - Limit Switch
2NC/2NO
Actuator Location
Top
Boot Sealed Actuator (Limit Switch)
No
Limit Switch Style
General Purpose Limit Switch
DC Contact Rating
10 A @ 250 V
Wiring Entry
1/2 in NPT
Roller Material
Steel
Stem Thread - Limit Switch
No Stem
Actuator Style (Limit Switch)
Plunger, Roller
Operating Force
2.9 in-lb
Voltage Rating
300VAC/250VDC
IP Rating
IP66
Number of Poles
2
Body Material
Metal
Differential Travel
0.03 in
Connection Type
Threaded Entry
Current Rating - nominal
10A
Pre-Travel - Travel To Operate
0.12 in (3mm) PT
Over-Travel/Total-Travel
0.118 in (3mm) OT
Body Construction
Die Cast Zinc
Operating Temperature - max
185 deg F (85 deg C)
Head/Operator
Top Push Roller
Differential-Travel - Travel To Reset
0.024 in (0.6mm) DT
Head Action
Spring Return, Standard
Electrical Rating - VAC/DC
10A 300Vac (Vdc Rated)
Operating Temperature - min
-40 deg F (-40 deg C)
Rating - NEMA
NEMA 4
Poles/Contacts
DPDT 2NO 2NC
Operating Temperature - Minimum
-40 Degrees F
Pretravel
0.12 in
Boot Sealed Actuator
No Boot Included
Mounting Hole Horizontal Center to Center Distance
42 mm
Directional Movement
Linear
Overtravel
0.12 in
Body Configuration
Non Plug-In
Number of Mounting Holes
4
NEMA Enclosure Rating
1, 12, 13, 4
Operating Torque - Maximum
2.9 in-lb
Mounting Hole Vertical Center to Center Distance
22 mm
Mounting Style
Surface
Operating Temperature - Maximum
185 Degrees F

Description

Limit Switch, Actuator Style - Limit Switch Plunger, Roller, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 10A @ 300V, DC Contact Rating - Limit Switch 10A @ 250V, Contact Form- Switches 2NC/2NO, Actuator Length - Limit Switch 1.89 in, Body Height - Limit Switch 2.37 in, Body Width - Limit Switch 2.56 in, Body Depth - Limit Switch 1.18 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 13, 4
