  9. Pump, Peristaltic, Max. Flow 23.50 gpd
Stenner Pump, Peristaltic, Max. Flow 23.50 gpd E20VXHA1S6G1 - main

Pump, Peristaltic, Max. Flow 23.50 gpd

  • Mfr # E20VXHA1S6G1

  • Zoro # G6036438

product price: $389.99
/ea
Free Shipping & Returns

Key Features

Body Material
Polycarbonate
Tubing Material - Peristaltic Pumps
Santoprene
Min. Flow Rate
2.70 gpd
Includes
20 ft Roll of Suction/Discharge Tubing, Pump Tube, Duckbill Check Valve, Weighted Suction Line Strainer, (3) 1/4 in Connecting Nuts, (3) 1/4 in Ferrules
HP - Pumps
1/40 hp
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
E20VXHA1S6G1
Zoro #
G6036438
UPC #
-
Country of Origin
United States

Dimensions

Height
5 1/2 in
Length
6 in
Width
3 3/4 in
Cord Length
6 ft
Overall Length
4.4 in
Discharge Connection Size
1/4 in
Overall Height
5.9 in
Intake Connection Size
1/4 in
Overall Width
5.2 in

Details

Body Material
Polycarbonate
Tubing Material - Peristaltic Pumps
Santoprene
Min. Flow Rate
2.70 gpd
Includes
20 ft Roll of Suction/Discharge Tubing, Pump Tube, Duckbill Check Valve, Weighted Suction Line Strainer, (3) 1/4 in Connecting Nuts, (3) 1/4 in Ferrules
HP - Pumps
1/40 hp
Seals and O-Rings - Pumps
Santoprene
Max. Flow (GPD) - Pumps
23.50 gpd
Turn Down Ratio - Pumps
8:1
Voltage - Pumps
115V AC
Phase - Pumps
1
Flow Rate Output Control
Variable
Max. Flow (gpd) - Pumps
23.50 gpd
Max. Pressure - Pumps
80 psi
Item
Chemical Metering Pump
Item - Chemical Metering Pumps
Chemical Metering Pump
Pump RPM
44 RPM
Self-Priming
Yes
cc/Min.
61.67cc/mín.
Standards
CE Certified, cULus Listed
Suction Lift
25 ft
Max. Viscosity - Pumps
100 cps
Features
Compact, Patented Quick Release Pump Head, Variable Output Adjustment
Motor RPM
3,250 RPM
Chemical Metering Pump Type
Peristaltic
Flow Rate
0.016 gpm/0.061Lpm
Reproducibility - Pumps
+/-5.0%
Head and Fitting Material - Pumps
Polycarbonate/Polypropylene/PVC
Number of Feeds
Single Head
Hz
60
Pressure (Maximum)
80 psi
Head Material
Polyethylene
Viscosity (Maximum)
100 cps
Flow Rate (Maximum)
23.5 gpd
Duty Cycle
Continuous
Frequency
60 Hz
Reproducibility
+/-5.0%
Electrical Connection Type
Plug-In
Seal Material
Santoprene
Nameplate Voltage
120V AC
Phase
Single
Motor Type
Brushed DC
Media Temperature (Maximum)
104 Degrees F
Tubing Material
Santoprene
Ambient Temperature (Maximum)
104 Degrees F
Fitting Material
Polypropylene, PVC
Degassing Valve Included
No
Intake Connection Type
Tube
Horsepower (Maximum)
1/40 hp
Turn Down Ratio
8:1
Priming
Self-Priming
Motor Enclosure
Totally Enclosed
Chemical Compatibility
Ammonium Hydroxide, Antifreeze, Hydrochloric Acid 10%, Hydrochloric Acid 20%, Hydrochloric Acid 30%, Phosphoric Acid 100%, Phosphoric Acid 40%, Phosphoric Acid 50%, Phosphoric Acid 60%, Phosphoric Acid 70%, Phosphoric Acid 80%, Phosphoric Acid 90%, Potassium Hydroxide 50%, Sodium Hydroxide 20%, Sodium Hypochlorite 10%, Sodium Hypochlorite 5%, Sulfuric Acid 10%, Sulfuric Acid 20%, Sulfuric Acid 30%, Sulfuric Acid 40%, Water
Roller Material
Polyethylene
Housing Material
Polycarbonate
Media Temperature (Minimum)
32 Degrees F
Motor Speed (Maximum)
3,250 RPM
Discharge Connection Type
Tube
Flow Rate (Minimum)
2.94 gpd
Control Programs
Manual Control

Description

Peristaltic Chemical Metering Pump, Control Programs Manual Control, Discharge Connection Size 1/4 in, Discharge Connection Type NPT, Flow Rate (Maximum) 23.5 gpd, Flow Rate (Minimum) 2.94 gpd, Horsepower (Maximum) 1/40 hp, Intake Connection Size 1/4 in, Intake Connection Type NPT, Media Temperature (Maximum) 104 Degrees F, Media Temperature (Minimum) 32 Degrees F, Nameplate Voltage 120V AC, Number of Feeds 1, Pressure (Maximum) 80 psi, Reproducibility +/-5.0 Percent, Tubing Material Santoprene
