Condenser Fan Motor, 1/2 HP, 48Z Frame

  • Mfr # 048A17O153
  • Zoro # G7343627

product price:
$
220.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Permanent Split Capacitor
Phase
Single
HP
1/2
RPM Range
1,601-1,700
No. of Speeds
3
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
048A17O153
Zoro #
G7343627
UPC #
-
Country of Origin
Mexico
Item
Fan and Blower Motor
Motor Design
Permanent Split Capacitor
Phase
Single
HP
1/2
RPM Range
1,601-1,700
No. of Speeds
3
Voltage
115V AC
Motor Shaft Rotation
CW/CCW
Frame
48Z
Motor Enclosure Design
Open Air-Over
Motor Mounting Type
Ring/Stud
Motor Mounting Position
Horizontal
Motor Thermal Protection
Auto
Max. Ambient Temp.
40 Degrees C
Nameplate RPM
1,625 RPM
Motor Application
HVAC/R
Motor Sub Application
Direct Drive Fan/Blower
Voltage Compatibility
115V AC, 208V AC to 230V AC, 115V AC, 230V AC, 115V AC, 120V AC, 240V AC, 120V AC
Motor Bearings
Ball
Application
Fan/Blower
Full Load Amps
7.4 A
Duty
Continuous
Hz
60 Hz
Motor Service Factor
1
Ring to Ring Center
5 13/16 in
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Capacitor Required
Capacitor Included
Stud Quantity
4
Standards
CSA (LR2025), UL (E6312)
Motor Shaft Design
Flat
Ins. Class
B
Nominal Efficiency
0.72 %
Conduit Box Location
Exterior
Duty Cycle
Continuous
Motor Frame Material
Steel
Usable @ 208V
Not Usable at 208V
Weight
16 lb
Usable @ 200V
Not Usable at 200V
Conduit Box Position
F1
Number of Shafts
1
Nameplate Service Factor @ 60 Hz
1
Shaft Design
Flat
Manufacturers Warranty
1 yr
Number of Speeds
3
Frame Material
Steel
Wattage
370 W
Product Type
Fan and Blower Motor
Ambient Temperature - Maximum
40 Degrees C
Mounting Position
Horizontal
Full Load Current @ 60 Hz
7.4 A
Motor Enclosure Type
Open Air Over
Insulation Class
B
Sub Application
General Purpose
Frequency
60 Hz
Drive Type
Direct Drive
Bearing Type
Ball
Efficiency Rating
Standard Efficiency (IE1)
Nameplate Voltage @ 60 Hz
115V AC
Nameplate Horsepower @ 60 Hz
1/2 hp
Nameplate RPM @ 60 Hz
1,625 RPM

Dimensions

Shaft Dia.
1/2 in
Shaft Length
4 1/16 in
Overall Length
10 1/4 in
Stud Size
#8-32
Length Less Shaft
6 3/16 in
Manufacturers Warranty Length
1 yr
Resilient Ring Dia.
2 1/4 in
Bolt Circle Dia.
5 1/8 in
Body Dia.
5 11/16 in
Lead Length
30 in
Body Diameter
5.7 in
Shaft Diameter
1/2 in
Bolt Circle Diameter
5 1/8 in
Frame Size
48Z
Mounting Stud Thread Size
#8-32
Resilient Ring Diameter
2 1/4 in
Wire Rope Length
10 1/4 in
Length
10 1/4 in

Description

Fan and Blower Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/2 hp HP, Nameplate RPM 1,625 RPM, No. of Speeds 3, Voltage 115V AC, 7.4 A Full Load Amps, 48Z Frame, Output Watts 370 W, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over
