  11. HazardousLocationMotor, 1-1/2hp, 3450RPM
No Product Image Available

HazardousLocationMotor, 1-1/2hp, 3450RPM

  • Mfr # 114424.00

  • Zoro # G011935589

product price: $1,211.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Capacitor-Start
Phase
Single
HP
1 1/2 hp
RPM Range
3,001-3,600
Voltage
115/208-230V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
114424.00
Zoro #
G011935589
UPC #
691720013946
Country of Origin
Mexico

Dimensions

Overall Length
14 7/16 in
Length Less Shaft
12 9/16 in
Shaft Length
1 7/8 in
Lead Length
8 in
Shaft Dia.
5/8 in

Details

Motor Design
Capacitor-Start
Phase
Single
HP
1 1/2 hp
RPM Range
3,001-3,600
Voltage
115/208-230V AC
Frame
56C
Hazardous Location Class
Class I, Class II
Motor Thermal Protection
Auto
Motor Enclosure Design
Totally Enclosed Fan Cooled
Motor Mounting Type
C-Face
Max. Ambient Temp.
40 Degrees C
Nominal Efficiency
77 %
Nameplate RPM
3,450 RPM
Motor Service Factor
1
Motor Application
Hazardous Location
Duty Cycle
Continuous
NEMA Design
L
Weight
37 lb
Usable @ 200V
Not Usable at 200V
Full Load Amps
7.7 A
Motor Shaft Rotation
CWSE
Motor Frame Material
Steel
Hazardous Location Division
Division I
Temp. Code
T3B
Usable @ 208V
Usable at 208V
No. of Speeds
1
Motor Mounting Position
Horizontal
Includes
Explosion Proof Conduit Box
Voltage Compatibility
115V AC, 208V AC, 230V AC
Standards
CSA Certified, UL Listed
Item
Hazardous Location Motor
Motor Bearings
Ball
Motor Shaft Design
Keyed
Ins. Class
B
Hz
60 Hz
Hazardous Location Group
Group C, Group D, Group F, Group G

Description

Hazardous Location Motor, Single Phase, Motor Design Capacitor-Start, 1 1/2 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 7.7 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Max. Ambient Temp. 40 Degrees C, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Hazardous Location Class Class I, Class II, Temp. Code T3B, Motor Enclosure Design Totally Enclosed Fan Cooled, Duty Cycle Continuous
