  11. WashdownMotor, 2hp, 1745RPM, 230/460VAC
No Product Image Available

WashdownMotor, 2hp, 1745RPM, 230/460VAC

  • Mfr # 121913.00

  • Zoro # G011931239

product price: $1,196.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Three-Phase
Phase
Three
HP
2 hp
RPM Range
1,701-1,800
Voltage
230/460V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
121913.00
Zoro #
G011931239
UPC #
691720345788
Country of Origin
United States

Dimensions

Manufacturers Warranty Length
Not available
Body Dia.
7.4 in
Bolt Circle Dia.
5 7/8 in
Shaft Dia.
7/8 in
Shaft Length
2 1/8 in
Stud Size
3/8"-16
Overall Length
14 1/4 in
Length Less Shaft
11 1/2 in

Details

Item
Washdown Motor
Motor Design
Three-Phase
Phase
Three
HP
2 hp
RPM Range
1,701-1,800
Voltage
230/460V AC
Frame
145TC
Motor Frame Material
Stainless Steel
Motor Thermal Protection
None
Motor Enclosure Design
Totally Enclosed Fan Cooled
Standards
CE, CSA Certified, UL Listed
Includes
Not available
Bearing Protection
Not available
Motor Shaft Design
Keyed
Motor Bearings
Ball
Service Factor @ 50Hz
1.25
Duty Cycle
Continuous
Full Load Amps @ 50Hz
2.0 A
Motor Application
General Purpose
Hz
60/50 Hz
Motor Shaft Rotation
CW/CCW
Usable @ 200V
Not Usable at 200V
Ins. Class
F
Motor Mounting Type
C-Face, Rigid Base
NEMA Design
B
Usable @ 208V
Not Usable at 208V
Finish
No Paint
Voltage Compatibility
230V AC, 460V AC
Endshield Material
Aluminum
No. of Speeds
1
Max. Ambient Temp.
40 Degrees C
Nameplate RPM
1,745 RPM
RPM @ 50Hz
1,435 RPM
Motor Service Factor
1.25
Shaft Material
Stainless Steel
Nominal Efficiency
86.5 %
Voltage @ 50Hz
190/380V AC
Motor Mounting Position
Horizontal
HP @ 50Hz
2 hp
Full Load Amps
5.8/2.9 A
Weight
50 lb
Conduit Box Position
F1

Description

Washdown Motor, Three Phase, Motor Design Three-Phase, 2 hp HP, Nameplate RPM 1,745 RPM, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 5.8/2.9 A, 145TC Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60/50 Hz Hz, Motor Service Factor 1.25, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, NEMA Design B, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Fan Cooled
