Voltage 115VAC
Application Diesel Exhaust Fluid, Anti-Freeze, Clean Water
HP 1/10
Housing Material Polypropylene
GPM 8
Seal Material EPDM
Pump Design Nutating Diaphragm
Self-Priming Yes
Seal Type Mechanical
Max. Viscosity 10 cps
Item Electric Drum Pump
Bearing Type Sealed Ball
Max. Specific Gravity 1.09
Motor Type 2 Pole
Motor Enclosure IP55
For Use With Anti-Freeze, Clean Water, Diesel Exhaust Fluid
pH Range 5.0 to 10
Wetted Materials EPDM, Polypropylene, Stainless Steel
Nozzle Type Automatic
Features Dispenses 8 gpm
Suction Lift 6 ft.
Inlet 3/4"
Duty Cycle Intermittent
Max. Temp. 104 Degrees F
Hz 60
Agency Compliance ISO
Duty Intermittent
Max. Pressure 25 psi
Pressure Range 23 psi
Amps 3.5
Transfer Pump Application Agriculture, Automotive, Construction, Farming, Industrial, Marine, Trucking
Metered Yes
Nozzle Material Stainless Steel
Adapter Material 316 Stainless Steel
Hose Material Peroxide Cured EPDM
Shaft Material Stainless Steel
Bypass Valve Internal
Max. GPM for Water 8
Gasket Material EPDM
Adapter Type RSV
Max. Liquid Temp. 104 Degrees F
Max. Head 48 ft.
Phase Single
Includes Coupler, Drip Cup, Hose, Nozzle Hanger, Reel, Tote Mounting Plate
Pump Body Material Polypropylene
Food Grade No
Includes Spout Yes
Min. Fluid Temp. 17 Degrees F
Pump Connection Type Hose Barb
Runs Dry Yes
Spout Material 316 Stainless Steel
Variable Speed No
For Container Type Drum, Tote
Discharge Tube Outlet OD 1 in
Spout Connection Type Integral to Nozzle
Max. Head - Pumps 48 ft
Max. Fluid Temp. 104 Degrees F
Diesel Exhaust Fluid Compatible Yes
Includes Bung Adapter No
Noise Level 70 dB
Discharge Connection Type Hose Barb
Pump Connection OD 1 in
Housing Material - Pumps Polypropylene
Max. Oil Flow 8 gpm
Frequency (Hz) 60 Hz
Includes Discharge Hose Yes Not Recommended Chemicals
See full list of Not Recommended Chemicals Acetic Acid 80%,Acetone,Ammonia Liquid,Anhydrous Ammonia,Automatic Transmission Fluid,Biodiesel,Brake Fluid,Calcium Chloride,Chromic Acid 10%,Chromic Acid 30%,Chromic Acid 5%,Chromic Acid 50%,Concentrated Nitric Acid,Cyclohexane,Diesel Fuel,E85,Ethyl Acetate,Fertilizers,Formic Acid,Fungicides,Gasoline,Glacial Acetic Acid,Heptane,Herbicides,Hexane,Petroleum Oil,Synthetic Oil,Hydrazine,Hydrochloric Acid 100%,Hydrochloric Acid 20%,Hydrochloric Acid 37%,Hydrofluoric Acid 100%,Hydrofluoric Acid 20%,Hydrofluoric Acid 75%,Kerosene,Lacquer Thinners,Lithium Grease,Methanol,Methyl Chloride,Methyl Ethyl Ketone,Motor Oil,Naphtha,Nitric Acid 10% Solution,Nitric Acid 20% Solution,Nitric Acid 50% Solution,Paint,Paint Thinner,Pesticides,Phosphoric Acid 40% Solution,Sodium Bisulfate,Sodium Hydroxide 20%,Sodium Hydroxide 50%,Sodium Hydroxide 80%,Stoddard Solvent,Sulfuric Acid 10% to 75%,Sulfuric Acid 75% to 100%,Sulfuric Acid up to 10%,Toluene,Trichlorethylene 50%,Turpentine,Windshield Washer Fluid,Xylene
Number of Phases 1
Suction Tube Material EPDM
Includes Suction Tube Yes
Motor HP 1/10 hp
Suction Tube ID 3/4 in
Suction Tube OD 1 in
Hose Tube Material EPDM
Discharge Tube Outlet ID 3/4 in
Power Source Corded Electric
Includes Nozzle Yes
Motor RPM 1,750 RPM
Nozzle Operation Automatic
For Media Type Acetic Acid, Ammonium Hydroxide, Antifreeze, Bleach, Citric Acid, DEF, Ethanol, Ethylene Glycol, Formaldehyde, Glycerin, Isopropanol, Potassium Hydroxide (50%), Sodium Bicarbonate, Sodium Bisulfite, Water
Max. Flow Rate 8 gpm
Max. Head Pressure 23 psi
Hose Cover Material Thermal Plastic
Full Load Amps 4.5 A Compatible Chemicals
See full list of Compatible Chemicals Acetic Acid 20%,Ammonium Hydroxide,Antifreeze (Coolant),Citric Acid 50%,DEF,Deionized Water,Ethyl (Ethanol),Ethylene Glycol,Formaldehyde,Formaldehyde 40%,Fresh Water,Glycerin,Isopropyl (Isopropanol),Potassium Hydroxide (50%),Salt Water,Sodium Bicarbonate (10%),Sodium Bisulfite,Sodium Hypochlorite/Bleach (to 20%)
Explosion Proof No
Grease NT
Gear Lube NT
Max. Outlet Pressure 23 psi
Rated Voltage 115 V AC
Maximum Flow Rate 8 gpm
Nozzle Fluid Compatibility DEF
Adapter Connection Standard Buttress
Static Protection Not Groundable
Housing Finish Powder Coated
Pump Connection ID 3/4 in
Chemical Compatibility Acetic Acid 20%, Ammonium Hydroxide, Antifreeze Coolant, Bleach, Citric Acid 50%, DEF, Deionized Water, Ethanol, Ethylene Glycol, Formaldehyde, Formaldehyde 40%, Fresh Water, Glycerin, Isopropanol, Potassium Hydroxide 50%, Salt Water, Sodium Bicarbonate 10%, Sodium Bisulfite
Full Load Current 4.5 A
Maximum Oil Flow 8 gpm
Maximum Head 48 ft
Motor Horsepower 1/10 hp
Wetted Material EPDM/Polypropylene/Stainless Steel
Maximum Fluid Temperature 104 Degrees F
Frequency 60 Hz
Minimum Fluid Temperature 17 Degrees F
Motor Enclosure Design Totally Enclosed Fan Cooled
Maximum Outlet Pressure 23 psi
Pump Technology Diaphragm
Motor Speed 1,750 RPM
Standards ISO
Meter Type Included Digital
Hazardous Location Class Not Rated
Meter Unit Of Measure Gallons, Liters
Mount Type Foot
Maximum Viscosity 10 cps
Maximum Head Pressure 23 psi
Plug Type NEMA 5-15-P
Power Source - TS Only Corded Electric
