Shop LITTLE GIANT PUMP

Pump, 4-1/2 In. L, 4-1/2 In. W, 4-5/8 In. H

  • Mfr # 501203

  • Zoro # G2894421

product price:  $140.99
/ea
Free Shipping & Returns

Key Features

HP
1/150 hp
Voltage
115V
Full Load Amps
1.1 A
Cord Length
6 ft
Impeller Material
Nylon
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
501203
Zoro #
G2894421
UPC #
010121019850
Country of Origin
Mexico

Dimensions

Cord Length
6 ft
Length
4 1/2 in
Height
4 5/8 in
Width
4 1/2 in
Overall Height
4.6 in
Compatible Discharge Pipe Size
1/4 in
Overall Width
4.5 in
Overall Length
4.5 in
Compatible Intake Pipe Size
1/2 in
Inlet Diameter
1/2 in
Discharge Diameter
1/4 in

Details

Item
Centrifugal Pump
HP
1/150 hp
Voltage
115V
Full Load Amps
1.1 A
Impeller Material
Nylon
Duty
Continuous
Max. Head
7.4 ft
Seal Material
Nitrile
Outlet
1/4 in (M)NPT
Features
In-line or Submersible
Agency Compliance
UL
Housing Material
Nylon
Overload Protection
yes
Inlet
1/2 in (M)NPT
GPH of Water @ 5 Ft. of Head
120
Inlet Type
1/2 in (M)NPT
GPH of Water @ 1 Ft. of Head
205
Amps
1.1 A
Discharge Type
NPT
Horsepower
1/150 hp
Duty Cycle
Continuous
Maximum Feet of Head
7.4 ft
Flow Rate @ 5 ft of Head (Maximum)
120 gph
Flow Rate @ 1 ft of Head (Maximum)
205 gph
Intake Type
NPT
Pumping Application
Coolant Recirculating, Liquid Transfer
Standards
UL Listed
Pump Housing Material
Glass Filled Nylon
Nameplate Voltage
115V AC
Compatible with Media Type
Oil
Motor Sealing
Oil-Filled
Drive Coupling Type
No Coupling
Phase
Single
Feet of Head (Maximum)
7.4 ft
Chemical Compatibility
Oil
Ambient Temperature - Minimum
30 Degrees F
Full Load Current
1.1A
Pump Design
Submersible
Number of Stages
1
Shaft Seal Material
Buna-N
Flow Rate (Maximum)
205 gph
Suction Lift (Maximum)
0 ft
Case Pressure - Maximum
3.21 psi
Media Temperature - Minimum
30 Degrees F
Ambient Temperature - Maximum
120 Degrees F
Media Temperature - Maximum
120 Degrees F

Description

Centrifugal Pump, Pump Housing Material Glass Filled Nylon, Horsepower 1/150 hp, Nameplate Voltage 115V AC, Flow Rate @ 1 ft of Head (Maximum) 205 gph, Flow Rate @ 5 ft of Head (Maximum) 120 gph, Flow Rate @ 10 ft of Head (Maximum) Not Applicable, Maximum Feet of Head 7.4 ft, Compatible Intake Pipe Size 1/2 in, Compatible Discharge Pipe Size 1/4 in, Intake Type NPT, Discharge Type NPT, Cord Length 6 ft, Motor Sealing Oil-Filled, Amps 1.1 A, Compatible with Media Type Oil, Duty Cycle Continuous
