  11. Lug Compression Connector, 450 kcmil Max, 1 to 2 in Stud, Standard Barrel, Copper, Brown
Panduit Lug Compression Connector, 450 kcmil Max, 1 to 2 in Stud, Standard Barrel, Copper, Brown LCAX450-12-6 - main

Lug Compression Connector, 450 kcmil Max, 1 to 2 in Stud, Standard Barrel, Copper, Brown

  • Mfr # LCAX450-12-6

  • Zoro # G0774188

product price: $40.65
/ea

Key Features

Cable Size
450 kcmil
Connector Type
Standard Barrel
Width
1.7"
Material
Copper
Length
3.6"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX450-12-6
Zoro #
G0774188
UPC #
7498343597
Country of Origin
Mexico

Dimensions

Cable Size
450 kcmil
Width
1.7"
Length
3.6"
Overall Length
3.6 in
DLO Copper Flex Conductor Size (kcmil)
444.4
Barrel Length (In.)
1.4
Class K Copper Flex Conductor Size (kcmil)
450
Class M Copper Flex Conductor Size (kcmil)
450
Overall Length (mm)
91.4
Tongue Thickness (In.)
0.26
Wire Strip Length (In.)
42376
Class G Copper Flex Conductor Size (kcmil)
450
Tongue Width (mm)
43.2
Wire Strip Length (mm)
36.32
Stud Hole Size (In.)
1 to 2
Class I Copper Flex Conductor Size (kcmil)
450
Tongue Thickness (mm)
6.6
Inside Diameter (In.)
0.92
Outer Diameter (mm)
30.22
Tongue Width (In.)
1.7
Outer Diameter (In.)
1.19
Class H Copper Flex Conductor Size (kcmil)
450
Stud Hole Size (mm)
12.7
Barrel Length (mm)
35.6
Overall Length (In.)
3.6
Inside Diameter (mm)
23.36
Tongue Width
1.70 in
For Wire Size
450 kcmil
Barrel Size
Standard
For Stud Size
1 to 2 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Brown
Item
Lug Compression Connector
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Die Code
20
Features
Angled Connector, Corrosion Resistant
Panduit Die Index Number
P87
Product Type
Copper Compression Connectors - Lugs
T & B Die Index Number
20
Finish/Coating
Tin-Plated
Maximum Voltage (kV)
35
Base Material
Copper
Tongue Angle
Straight
Lug Type
1 Stud Hole Lug
Burndy Die Index Number
20
UL Temperature Rating (°C)
90
Tongue Type
Standard
Product Material
Copper
Connector Details
1 x Terminal
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,450 Kcmil
