Safety Relay

Industrial safety relay designed for emergency stop (E-STOP) and safety gate monitoring with time-delay function. It provides reliable controlled shutdown of machinery with selectable delay times for safer machine stopping in automation systems. Specifications: -Type: Safety Relay (Time-Delayed) -Series: PNOZ XV2 -Supply Voltage: 24V DC -Inputs: 1-/2-channel safety input with short-circuit detection -Safety Outputs: 2 N/O (instantaneous) + 2 N/O (delayed) -Contact Rating: Up to 8 A (AC/DC1) -Switching Voltage: 240V AC / 24V DC -Delay Function: Adjustable 0.1 s to 30 s (multiple selectable steps) -Delay Mode: Delay-on de-energisation -Reset Mode: Automatic / manual selectable -Mounting Type: DIN Rail (45 mm width) -Connection Type: Screw terminal -Housing Material: ABS / Polycarbonate (flame retardant UL 94 V0) -Protection Class: IP40 (housing), IP20 (terminals) -Operating Temperature: -10 deg C to +55 deg C -Mechanical Life: High endurance industrial grade -Application: E-STOP, safety gates, delayed machine shutdown -Standards: EN ISO 13849-1, EN 60204-1, EN 60947-5-1
