Shop RHEEM

10 gal, 120V, 12.5 A Amps, Commercial Mini Tank Water Heater

  • Mfr # EGSP10

  • Zoro # G5127044

product price:
$
854.99
/ea
Free Shipping & Returns

Key Features

Voltage
120V
Amps AC
12.5 A
Height to Cold Side Connection
4 1/4 in
Commercial / Residential
Commercial
Recovery @ 100 F Rise
6 gph
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
EGSP10
Zoro #
G5127044
UPC #
020352472546
Country of Origin
United States
Item
Electric Water Heater
Voltage
120V
Amps AC
12.5 A
Commercial / Residential
Commercial
Recovery @ 100 F Rise
6 gph
Standards
ASME, CSA Certified, UL Listed
Compliance
Design Certified Under UL Standard 174., Exceed the Minimum Energy Factor Requirements of ASHRAE, Exceeds Energy Effeciency Codes of all States, Tested Cccording to DOE Test Procedures
Industry Type
Commercial
Phase
Single
Temp. Range
110 Degrees to 170 Degrees F
Recovery @ 140 F Rise
4 gph
Water Connection
3/4 in NPT
Residential / Commercial
Commercial
Tank Capacity - Plumbing
10.0 gal
Water Heater Design
Point-of-Use
Item - Water Heaters
Mini Tank Water Heater
Total Watts
1,500 W
Features
Automatic Temperature Control
System of Measurement
Inch
Tank Capacity
10 gal
Includes
Resistor Elements, Surface Mounted Thermostat
Recovery @ 120 F Rise
5 gph
Phase - Water Heaters
1
Connection Location
Side
Fuel Type
Electric
Vent Type
Standard
Number of Elements
1
Connection Type
NPT
Max. Pressure
150 psi
Voltage - Water Heaters
120
Cold Inlet Type
NPT
Mounting Type
Wall Mounting
Automatic Thermostat
Yes
Tank Insulation Material
Polyurethane
Thermal Efficiency
Not Rated
Current
12.5 A
Thermostat Mounting
Surface
Environment
Indoor
Water Connection Location
Side
Maximum Recovery Flow Rate
15 gph @ 40 Degrees F
Included Valves
Temperature and Pressure Relief
Maximum Water Pressure
150 psi
Power Consumption
1,500 W
Recovery Rate @ Rise
10 gph @ 60 Degrees F, 15 gph @ 40 Degrees F, 4 gph @ 140 Degrees F, 5 gph @ 120 Degrees F, 6 gph @ 100 Degrees F, 8 gph @ 80 Degrees F
Tank Outer Shell Material
Steel
Overheat Protection
Yes
Minimum Delivered Temperature
110 Degrees F
Hot Outlet Type
NPT
Maximum Delivered Temperature
170 Degrees F
Market
Commercial
Operating Voltage
120V AC
Tank Outer Shell Finish
Porcelain Enamel

Description

Electric Water Heater, Operating Voltage 120V, Phase Single, First Hour Rating Not Applicable, Maximum Recovery Flow Rate 15 gph @ 40 Degrees F, Overall Height 22.87 in, Overall Width 15.75 in, Power Consumption 1,500 W, Tank Capacity 10 gal, Tank Diameter 15.75 in, Market Commercial, Number of Elements 1, Automatic Thermostat Yes, Cold Inlet Size 3/4 in, Cold Inlet Type NPT, Current 12.5 A, Environment Indoor, Features Automatic Temperature Control, Height to Cold Inlet 4.25 in
